35m-4.4g Signal Source Adf4351 Development Board Control For Frequency Sweep

US $44.21

???, ???, China
Jun 9th

Open on mobile:
QR code

35M-4.4G signal source ADF4351 development board control FOR frequency sweep Description: 1, the output frequency range: 35 m - 4.4 G (ADF4351 ) 2, mode of power supply: 5 V 3, the control mode: three line SPI, ADI original PC control software, which can realize all the functions, including frequency, frequency sweep and frequency hopping. 4, the default + - 50 PPM 25 m crystals, phase noise - 112 DBC @ 10 k See below 5, test data and software. Will be near zero DBM. 35 M to 137.5 M phase noise is better than 110 DBC @ 10 k 1 G is better than 100 DBC @ 10 k 2 G is better than 93 DBC @ 10 k 2.2 G is better than 91 DBC @ 10 k 4.4 G is better than 82.3 dBc @ 10 k Better than 86.6 dBc @ 100 k Better than 102 DBC @ 200 k Second harmonic VCO 2.2 G - 4.4 G DBC with this data sheet is very close,ADF4351 the actual phase noise to slightly better than that of ADF4350 , figure was based on the data of ADF4350 test. A lot of people ask the source is a square wave and sine wave, 35 m - 2.2 G frequency division is done so is a square wave, 2.2 G - 4.4 G broadband VCO is internal, such as sine radio frequency signal source, please contact me the default output use broadband matching, the amplitude of points will be near zero DBM, if need to match the characteristic frequency point, please make your own match. test data diagram test instrument 100 hz RBW - 8 g spectrum instrument, VBW 300 hz, can actually instrument to 10 hz RBW, because balance test speed, so the measured phase noise will be better than the below value, if there is a better phase noise spectrum, phase noise can test. 137.5 M test pattern 200M test pattern 500M test pattern 1G test pattern 2G test pattern 2.2G test pattern 4G test pattern Dear buyers: Welcome to our store,Thanks! We try our best to provide you high quality and good service.Your satisfy is our aim. If you are satisfy with us,pleae leave five star positive feeback,and welcome to our store again,we will supply the good items and service all the time. If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve for you. Best Regards Shipping: We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Warranty and return: 12-months Warranty for defective items (excluding items damaged and/or misused after receipt). Refund or replacement request is available only the requests within 1 week after parcel received & returning the item as the same condition as received. Please contact us to request a return authorization. Your name, auction number, and reason for return should be included in the email. All items returned must contain all original packaging materials. Please repack the item carefully. Items returned will be tested and a new replacement will be shipped to the buyer immediately when found defective. In the event that a suitable replacement is not available then a refund will be issued. Shipping, handling and insurance fees are non refundable. Return shipping is to be paid by the Buyer. Contact us: We have much more products, if you need or have any question ,please contact us by leaving message or use Ali Trade manager .Welcome to wholesale. Thank you so much!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
MPN	Does Not Apply
Model	new
Country/Region of Manufacture	China
UPC	Does not apply
