39.4" X 39.4" Pallet Okk Hm100s Cnc Large Capacity Horizontal Machining Center

US $295,000.00

Prospect Heights, Illinois, United States
Jan 30th

Open on mobile:
QR code

. GRAY MACHINERY COMPANY . 800-292-1493 * 847-537-7700 * FAX 847-537-9307 77 E. PALATINE ROAD * PROSPECT HEIGHTS, IL 60070-1811 WEB: www.graymachinery.com * EMAIL: sales@graymachinery.com PROPOSAL Stock 00011328 Quote # 282357 We are pleased to submit for your consideration: OKK MODEL HM100S CNC LARGE CAPACITY HORIZONTAL MACHINING CENTER SERIAL NUMBER NA NEW 2004 GENERAL SPECIFICATIONS: Number of Pallets 2 Pallet Size 39.4" x 39.4" Pallet Load Max. 5,512 lbs Pallet change time 15 sec. Table indexing 1 deg index Traverses: X 55.12" Y 43.31" Z 39.4" Spindle Nose to Table 1.97" - 45.28" Feeds (X/Y/Z) 1889 IPM Rapids (X/Y/Z) 4500 mm/min Spindle Taper CAT 50 Spindle bearing diameter 100mm Spindle Drive Motor 40/30 HP Spindle speed Max. 12,000 RPM Spindle Torque Max. 420 Nm Tool Taper 50 Tool Magazine Positions 60 Tool diameter with/without adjacent tools Max. 115/270mm Tool length Max. 500 mm Tool weight Max. 25 kg Tool-to-tool time 2.5 sec. Chip-to-chip time 6 sec. Machine weight approx. 25,000 kg EQUIPPED WITH: VIDEO: https://www.youtube.com/watch?v=5jQym9A1OlY Fanuc 160i CNC Controls (2) 39.4" x 39.4" Pallets High Pressure Coolant 1000 PSI thur Spindle Total Enclosure & Chip Conveyor 60 Position Automatic Tool Changer NOTE: ONLY CUT ALUMINUM, 15,125 HOURS, CURRENTLY IN OPERATION, CALL TO SCHEDULE AN IN PLANT DEMONSTRATION, GLENN GRAY 847-537-7700 X 601
