3g Hd-sdi Pattern Generator And Hdmi To Sdi Converter (cineroid & Phabrix Alt.)

US $6900

Pasadena, California, United States
May 29th

Open on mobile:
QR code

3G HD-SDI / SD-SDI 1080p Signal Pattern Generator and HDMI to SDI converter. NTSC & PAL ( Comparable with ESE DV-229 HD/SD SDI Pattern Generator) (Comparable with ikan VideoForge SDI/HDMI Video Test Pattern Generator) QuestTel's 1B-SDI-PTG 3G-HD/SD SDI Pattern Generator - advanced SDI pattern generator with multi-format and multi-pattern support. Supports still and moving video test patterns, and provides a lot of useful features like audio SMPTE-291M. 1B-SDI-PTG Pattern Generator supports up to 8 channels of AES compliant audio with 48KHz sample rate. Multitasking of 1B-SDI-PTG comes from bypassing HDMI input which allows user to use more testing patterns for connected display or use 1B-SDI-PTG as SDI converter with 3G support. 1B-SDI-PTG was designed with 4 control buttons and LCM screen for easy track and control.This SDI Pattern Generator offers a simple and effective way to calibrate and test SDI video displaysand other devices. Another attractive feature of Pattern Generator comes from bypassing HDMI input and allows users with more testing patterns for connected display or treats Pattern Generator as an advanced HDMI to SDI converter with 3G capability. With portable size, Pattern Generator is equipped four buttons and LCM screen to ease the control. This device provides a cost effective way to calibrate and test SDI enable video devices and displays. The 3G/HD/SD-SDI Pattern Generator can help to calibrate and set-up a camera quickly. Features: Supported output video resolution: SD-SDI: NTSC 525 @60Hz, PAL 625 @50Hz HD-SDI: 720p @50Hz, 59.94Hz, 60Hz 1080i @50Hz, 59.94Hz, 60Hz 1080p @23.98Hz, 24Hz, 25Hz, 29.97Hz, 30Hz 3G-SDI: 1080p@50Hz, 59.94Hz, 60Hz Supported output audio format: SMPTE 291M, SMPTE 299M (8 channel audio, audio group can be adjusted Bit rate SD-SDI: 270Mbps HD-SDI: 1.485Gbps, 1.4835Gbps 3G-SDI: 2.97Gbps, 2.967Gbps Video Patterns 100% Color Bars, Borderline, Random Noise, Check Field, Black, Vertical Lines, Black / White alternate fields, Full Grey / Full White, Black to White Gradient, Random Generator for all still patterns, moving squares White noise, Inverse effect with still pattern, Scrolling Title (see Appendix for illustrations) Supports HDMI bypass mode Save settings to memory option ANC data: EDH (RP-165), SMPTE 352M, SMPTE291M Control: By LCM & Panel Buttons Video output: Dual 3G capable SDI output Diagram and Video Patterns Tech Specs Role of usage Pattern generator SDI standards 3G/HD/SD-SDI Auto SDI rate detection Yes Supported protocols SMPTE 259M (270Mbps / 360Mpbs) SMPTE 292M / HDTV (1.485 & 1.485/1.001Gbps) SMPTE 424/425M (2.97 & 2.97/1.001Gbps) Video bandwidth 2.97Gpbs Data rates 143/270/1483/1485/2967/2970 Mbps Video support [3G] 1080p@50/59.94/60 (4:2:2) [HD] 720p50/59.94/60, 1080p24/30, 1035i50/59.94/60, 1080i50/59.94/60 [SD] NTSC@59.94Hz, PAL@50Hz SDI signal type SMPTE-292M/259M/424M HDMI bypass Yes Output impedance 75 Ohm Cable (Belden 1694A) equalization / transmission [3G-SDI] up to 60m (190ft) [HD-SDI] up to 150m (500ft) [SD-SDI] up to 300m (1000ft) Audio support Yes PCB Stack-up 4-layer board [impedance control — differential 100 Ohm; single 50 Ohm] Input None Output 2x BNC [SDI] BNC connector 75 Ohm interlocking socket HDMI connector Type A [19-pin female] [HD] Eye pattern characteristics Amplitude: Within 800mV <10% Rise overshoot: Less than 2% Fall overshoot: Less than 2% Long time jitter <1.0 UI Timing jitter <1.0 UI Alignment jitter <0.2 UIt Dimensions [L x W x H] 150 x 190 x 32mm [5.9” x 7.5” x 1.3”] Weight 660g [1.5 lbs] Power supply 5V 4A DC Pdf User Guide Package includes 5V power supply unit Item Condition: NEW Shipping Agreemen: Buyer will pay actual shipping costs. Shipping costs based on weight TBD after auction. Item(s) will be shipped via USPS, UPS, & FedEx. Payment Information Paypal or wire transfer guarantees immediate shipping upon receipt and verification. Payment must be received within 3 days of the closing auction Terms & Conditions Please e-mail for any questions prior to bidding. We reserves the right to refuse a winning bid from a buyer with numerous negative feedback.
