3m 7622-t-110 Cold Shrink Silicone Rubber Termination Kit Qt-iii Medium Voltage

US $52

Newport, Washington, United States
May 29th

Open on mobile:
QR code

This 3MTM Cold Shrink QT-III Termination Kit has never been used. It is new old stock in its original unopened packaging in its original opened box. 7622-T-110, Non-Skirted, Tape, Wire and Unishield, 15 kV, 0.64-1.08 in (16,3-27,4 mm) Cable Insul. O.D., 3 termination/kit Manufacturer #: 7622-T-110 3M 7622-T-110 Medium Voltage Tubular Cold Shrink QT-III Termination Kit; 4/0 AWG-400 KCMIL AWG, 3/0 AWG-300 KCMIL, 2-4/0 AWG PRODUCT DETAILS • One-piece versatile design, allowing quick installation and accommodating a wide range of cable sizes • Cold shrink delivery system for easy installation, simply place termination over prepared cable and unwind core to shrink into place (no force fit required) • Hi-K stress control, specially formulated high dielectric constant material minimizes surfaces stress by more uniformly distributing the electrical field over the entire surface of the insulator • Compact design provides for easier installation in restricted spaces • Silicone rubber insulators, EPDM stress control tubes, stress controlling compound and silicone sealing compound are compatible with all common solid dielectric insulations, such as polyethylene (PE), cross-linked polyethylene (XLPE) and ethylene propylene rubber (EPR) • Contains sufficient quantities of material to make three single-phase terminations (Lugs must be ordered separately) • 100%, 133% insulation level 3M 7260-T Series Cold shrink QT-III termination kit with high-k stress relief is designed for tape shield, wire shield and Unishield ® cables. Kit contains three high-k tracking resistance, silicone rubber terminations, three pre-formed ground braids, three constant force springs and three 1/2 Inch x 10 Inch EMI copper foil shielding tape 1181 strips. It also includes six strips Scotch ® mastic strip 2230, a cable cleaning preparation kit CC-2 and an instruction sheet. It is ideal for 5 kilo-Volts cable with 4/0 AWG-400 kcmil conductor size and 8 kilo-Volts cable with 3/0 AWG-300 kcmil conductor sizes. Kit is perfect for 15 kilo-Volts cable with 2 kcmil-4/0 AWG conductor size. Cable has 0.64 Inch x 1.08 Inch primary insulation O.D and 0.97 Inch x 1.48 Inch jacket O.D. Tubular termination kit is compatible with 1/0 AWG, 2/0 AWG, 1 AWG, 3/0 AWG, 4/0 AWG, 2 AWG, 400 kcmil, 300 kcmil, 350 kcmil and 250 kcmil conductor sizes. Erosion resistant kit has basic insulation level of 110 kilo-Volts. It offers high-K stress design that delivers lower surface stress resulting in a more compact termination. Cable insulation has outside diameter that ranges from 0.64 - 1.08 Inch. It offers high performance and easy installation when terminating outdoor and indoor medium voltage cable. Track resistant kit offers high UV stability. It meets IEEE standards. Application For Single Conductor Tape Shield, Wire Shield, UniShield® Cables, Indoor Applications BIL Rating 110 Kv Bil 110 kV Brand / Label 3M Cable Insulation Outer Diameter 0.64 to 1.08 in Cable Insulation Outside Diameter Range 0.64-1.08 in Cable Type Tape Shield; UniShield(R); Wire Shield Catalog Description Cold Shrink Termination Kit Non-Skirted (3 terms/kit) Catalog Number 7622-T-110 Color Dark Gray Commodity Code 6413 Conductor Max 400 mcm/5kV, 4/0 awg/15kV Conductor Min 4/0 awg/5kV, 2 awg/15kV Conductor Size 1 AWG; 1/0 AWG; 2 AWG; 2/0 AWG; 250 kcmil; 3/0 AWG; 300 kcmil; 350 kcmil; 4/0 AWG; 400 kcmil Connector Type Not Included Country of Origin US Includes: (3) Hi-K Tracking resistant silicone rubber terminations, (3) Pre-formed ground braids, (3) Constant force springs, (6) strips sealing mastic, (1) Cable preparation kit, (1) Instruction sheet Insulation 0.640 - 1.080 Inch OD Silicone Rubber Insulation Level 100%; 133% Insulation OD - Max 1.080 in Insulation OD - Min 0.640 in Insulator Design Tubular Insulator Material Silicone Rubber Insulator Type Tubular Kit Type Indoor Cable Termination Length 14.4000 Lug/Stem Connector Included in Kit No Manufacturer Series QT-III Maximum Installed Length 12.00 in Mfr/Vendor 3M Number Of Terminals 1 Number of Skirts 0 Number of Terminations 3 Product Type Termination Kit Standard IEEE Standards Conforms to the IEEE Standard 48-1990 Class 1 Requirements Temperature Rating 105 deg C Maximum, 140 deg C Overload Type Medium Voltage, Tubular, QT-III Series UPC 054007417606 Voltage Class 5-15 kV Voltage Rating 5/8/15 Kilo-Volt Wire Size 4/0 AWG-400 KCMIL (5 Kilo-Volt), 3/0 AWG-300 KCMIL (8 Kilo-Volt), 2-4/0 AWG (15 Kilo-Volt) feature#1 One-piece versatile design, allowing quick installation and accommodating a wide range of cable sizes feature#2 Cold shrink delivery system for easy installation, simply place termination over prepared cable and unwind core to shrink into place (no force fit required) feature#3 Hi-K stress control, specially formulated high dielectric constant material minimizes surfaces stress by more uniformly distributing the electrical field over the entire surface of the insulator feature#4 Compact design provides for easier installation in restricted spaces feature#5 Silicone rubber insulators, EPDM stress control tubes, stress controlling compound and silicone sealing compound are compatible with all common solid dielectric insulations, such as polyethylene (PE), cross-linked polyethylene (XLPE) and ethylene propylene rubber (EPR) feature#6 Contains sufficient quantities of material to make three single-phase terminations (Lugs must be ordered separately) feature#7 100%, 133% insulation level
