3m Microtouch System 17-8921-203 Touch Screen Capacitive 8.75in 5-pin Us Author

US $89.99

United States
Jan 29th

Open on mobile:
QR code

Authorized Distributor New - Factory Authorized Distributor - Factory Warranty http://www.onlinecomponents.com/datasheet/178921203.aspx?p=10000379 3M MicroTouch System 17-8921-203 Touch Screen Capacitive 8.75in 5-Pin Supplier: 3M Touch Systems Part No: 17-8921-203 RoHS: Yes Active Area: 222.25x178.82 mm Outline Dimensions: 243.08x194.31x146.05 mm Family: 17-8921-203 Input Type: N/A Supplier_Package: N/A Packaging: N/A Pin_Count: 5 Mounting: N/A Touch Technology: Capacitive LCD Size: 8.75 in Cable Interface: N/A Glass Thickness: 0.125 mm Light Transmission: N/A Operating Temperature: N/A Dimension: 194.31 x 146.05 x 3.18mm Specifications, Features, Applications 3M Touch Systems has more than 25 years of surface capacitive technology expertise and specifically designed the 3M MicroTouch System SCT3250EX to meet the performance requirements of display applications ranging from to 32 inches. As an all-glass design, the SCT3250EX touch system offers light transmission to 11.5% better than typical resistive sensors and 3.5% better than typical surface capacitive sensors (based on published specifications). With the combination of the 3M ClearTek proprietary hard coat and a scratch-resistant top coat, the 3M MicroTouch Sensor SCT3250 offers superior surface durability compared to typical resistive and surface capacitive solutions. This surface durability feature helps the SCT3250 touch sensor support heavy-use applications while maintaining its functional, optical and aesthetic characteristics. In addition to the superior 3M MicroTouch SCT3250 touch sensor design, the 3M MicroTouch Controller EX with its dedicated custom ASIC sets the performance standard for capacitive sensing electronics and offers industry-leading ESD protection (based on published specifications). The EX controller's proprietary firmware and patented algorithms dynamically adapt to changes in the application's environment to help maintain the initial video alignment of the display for the life of the product. And, due to the dedicated ASIC, the SCT3250EX touch system has a "minimum touch duration" that is 50% faster than typical surface acoustic wave and surface capacitive solutions (based on published specifications). · POS all-in-one devices· Information kiosks· Self-service systems· Ticketing machines· Gaming machines· Amusement stations· Industrial devices· Healthcare displays With millions of 3M surface capacitive touch systems in use around the world, the SCT3250EX touch system continues be a preferred touch solution for demanding applications, such as gaming and retail, that require 24/7 reliability. Feature All-Glass Solution with 3M ClearTek Hard Coat EX Electronics · High light transmission provides superior display performance· Superior surface durability maintains optical and functional performance· High MTBF provides reliable system performance· High ESD performance to meeting industry requirements· Dedicated ASIC creates fast, accurate touch response· Low surface energy resists surface scratching· Smooth surface for better drag and draw performance· Durable finish for easy-to-clean surface Light Transmission Input Method Accuracy Resolution Linearization Tail Connection 91.5% (±1.5%) Finger contact >99% of true position x 1024, but capable 16K x16K when used with EX controllers Factory linearized Solder-less design Glass Thickness Display Size Surface Scratch Resistance Sealing Cleaning RoHS Directive Compliant 0.125" (3.18 mm) Supported 5.7" (144.78 mm) 32" (812.80 mm) (standard and wide formats) Hardness MoHS 7 or higher to induce a functional failure 3M ClearTek hard coat NEMA / IP66, complete water-resistant seal compatible Water, isopropyl alcohol, or similar non-abrasive cleaners Yes Communication USB, Serial, USB HID Digitizer, Dual Mode (USB and Serial Dimensions 11.4 mm Operating Current USB: 75 mA (typical) Serial: 85 mA (typical) Sleep Current 500 uA Power Connection USB: 75 mA Serial: 85 mA Connectors 5-pin locking AMP (Touch side) 5-pin Molex (COM side) ESD ±8KV Contact, ±27KV Air Point Speed (PPS) 200 pps Minimum Touch Time 5.4 ms MTBF >700,000 hours 5 years on touch system Unlimited touch warranty Windows (32-and 64-bit)* Windows Vista (32-and 64-bit) Windows (32-and 64-bit) Windows 2000, Server 2003, Server (32-and 64-bit) Windows 98, 95, ME, 3.1x (32-bit) Windows CE, XPe, WePOS (32-bit) Linux Kernel 2.6, Kernel 2.4 (serial only)** Apple OSX (UPDD driver)** * 3M MicroTouch System SCT3250EX HID is Windows 7 Logo Compatible Limited MT7 features supported Surface Obstructions Withstands most surface contaminants Chemical Resistance ASTM-D-1308-02 and ASTM-F-1598-95 Liquid Resistance Liquids on screen do not impede touch performance Operating Temperature 70° C for the touch screen Storage Temperature -50°C and 85°C Humidity 90% RH from 35? C, non-condensing 3M Touch Systems Subsidiary of 3M Company 501 Griffin Brook Park Drive Methuen, MA 01844 U.S.A. 1-888-659-1080 www.3M.com/touch RoHS Directive compliant: In accordance with European Directive 2002/95/EC, "RoHS Directive compliant" means that the product or part does not contain any of the following substances in excess of the following maximum concentration values in any homogeneous material, unless the substance in an application that is exempt under RoHS: (a) 0.1% (by weight) for lead, mercury, hexavalent chromium, polybrominated biphenyls or polybrominated diphenyl ethers; or (b) 0.01% (by weight) for cadmium. Unless otherwise stated 3M in writing, this information represents 3M's knowledge and belief based on information provided by third party suppliers 3M. (9/06) IMPORTANT NOTICE TO PURCHASER: Specifications are subject to change without notice. These 3M Touch Systems' Products and software are warranted to meet their published specifications from the date of shipment and for the period stated in the specification. 3M Touch Systems makes no additional warranties, express or implied, including but not limited to any implied warranties of merchantability or fitness for a particular purpose. User is responsible for determining whether the 3M Touch Systems Products and software are fit for User's particular purpose and suitable for its method of production, including intellectual property liability for User's application. If the Product, software or software media is proven not to have met 3M Touch Systems' warranty, then 3M Touch Systems' sole obligation and User's and Purchaser's exclusive remedy, will be, at 3M Touch Systems' option, to repair or replace that Product quantity or software mediator to refund its purchase price. 3M Touch Systems has no obligation under 3M Touch Systems' warranty for any Product, software or software media that has been modified or damaged through misuse, accident, neglect, or subsequent manufacturing operations or assemblies by anyone other than 3M Touch Systems. 3M Touch Systems shall not be liable in any action against it in any way related to the Products or software for any loss or damages, whether non-specified direct, indirect, special, incidental or consequential (including downtime, loss of profits or goodwill) regardless of the legal theory asserted. (7/02)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MicroTouch
MPN	17-8921-203
Model	17-8921-203
MANUFACTURER	3M Touch Systems
