3m Rf Coaxial Cable Connector M17/60-rg142 / 10 Feet For Sma/n/bnc/uhf Connector

US $24.50

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

1pcs RF Coaxial cable M17/60-RG142 / 10 feet Click here - add $3 for registered airmail M17 Part No.: M17/60-RG142 PHYSICAL PROPERTIES Material Diameter(mm) 1. Inner conductor Sliver plated copper 0.93 2. Insulation PTFE 2.95 3. Outer conductor Sliver plated copper double braiding 3.95 4. Jacket FEP 4.95 ELECTRICAL PROPERTIES Nom. Capacitance Conductor to Shield(pF/m) 96.5 Nom. Characteristic Impedance(ohm) 50 Nom. Velocity of Propagation(ï¼…) 70 Min. Bend Radius(Install)(mm) 25 Voltage Rating(VMS) 1900 Max. Operating Frequency(MHz) 8000 Operating Temperature Rating(Â°C) -55+200 Nom. Attenuation Frequency(MHz) Nom. Attenuation(¯dB/m) 100 0.125 400 0.256 1000 0.420 3000 0.781 5000 1.050 RF Cable Guide 50 ohm Flexible Cable Cable Type Frequency Attenuation db/100ft shields Jacket/Diameter Conductor RG316 DC-3GHz 47dB@3GHz 1 x braid FEP/2.59mm stranded Micro Coax 1.13mm DC-6GHz 106dB@3GHz 1 x copper/tin FEP/1.13mm stranded Micro Coax 1.32mm DC-6GHz 76dB@3GHz 2 x copper/tin FEP/1.13mm stranded RG174 DC-2.5GHz 43dB@2.4GHz 1 x braid PVC/2.80mm stranded RG188 DC-3GHz 41dB@2.4GHz 1 x braid PFA/2.68mm stranded RG178 DC-3GHz 62dB@2.4GHz 1 x braid FEP/1.83mm stranded RG196 DC-3GHz 42db@2.4GHz 1 x braid PTFE/1.9mm stranded RG58 DC-3GHz 25db@2.4GHz 1 x braid PVC/4.95mm stranded RG142 DC-8GHz 21db@2.4GHz 2 x braid FEP/4.95mm solid RG223 DC-12.4GHz 22db@2.4GHz 2 x braid PVC/5.38mm solid RG400 DC-12.4GHz 24db@2.4GHz 2 x braid FEP/4.95mm stranded RG8 12db@2.4GHz PE/10.23mm RG213 DC-1GHz 12db@2.4GHz 1 x braid PVC/10.29mm stranded RG214 DC-11GHz 12db@2.4GHz 2 x braid PVC/10.80mm stranded LMR100 DC-5.8GHz 39dB@2.4GHz foil + braid PVC/2.79mm solid LMR400 DC-5.8GHz 7db@2.4GHz foil + braid PVC/10.29mm solid LMR195 DC-5.8GHz 18db@2.4GHz foil + braid PVC/4.95mm solid LMR200 DC-5.8GHz 17db@2.4GHz foil + braid PVC/4.95mm Solid LMR600 DC-5.8GHz 4db@2.4GHz foil + braid PVC/14.99mm solid 75 ohm Flexible Cable Cable Type Frequency Attenuation db/100ft Shield Jacket/Diameter Conductor RG179 DC-3GHz 27db@1GHz 1 x braid FEP/2.54mm stranded RG59 DC-1GHz 11db@1GHz 1 x braid PVC/6.15mm solid Semi-Rigid Cable Cable Type Frequency Attenuation db/100ft Shield Jacket/Diameter Conductor Flex .141" DC-34 GHz 30db@5GHz 1 x copper/tin 3.51mm solid Flex .086" DC-60 GHz 41db@5GHz 1 x coppter/tin 2.211mm solid Semi-Rigid 047 DC-110GHz 79db@5GHz 1.19mm solid Semi-Rigid 086 DC-60GHz 46db@5GHz 2.18mm solid Semi-Rigid 141 DC-35GHz 28db@5GHz 3.58mm solid More products in our store RP-SMA jack to CRC9 plug RA Huawei USB Modem RG174 F to SMA double plug straight connector for pigtail coaxial RG174 15cm Universal Fakra Plug "Z"to SMA male pigtail RG316 pigtail cable RG316 15cm SMA plug ST to MMCX male RA connector 6''15cm SMA Jack nut to MC-card RA pigtail micro coaxial cable 1.13mm N Jack bulkhead to SMA plug pigtail jumper cable RG316 15cm SMA plug to male connector for pigtail cable RG316 15cm IEC DVB-T TV PAL plug to SMA Jack RG174 cable jumper pigtail 15cm Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	CA-142X10FT
Country/Region of Manufacture	China
MPN	184
Cable Length	10 feet
