3pcs Motorola Mc3356dw Wideband Fsk Receiver Usa Seller 10-006

US $1.50

Pekin, Illinois, United States
Jan 29th

Open on mobile:
QR code

Product Information VISIT binaryelectronics.com FOR MORE PRODUCTS AND CHEAPER PRICES! Everyone that purchases an item from our store or on eBay, will get a chance to win 50% off their next order at binaryelectronics.com. One Giveaway every month and your name will be entered for each item purchased for that months drawing! You will be notified by E-Mail if your the winner! Motorola MC3356DW 3pcs Manufacturer: Motorola Part Number: MC3356DW Package: SO-20L Lead/Terminal Type: Surface Mount Number Leads/Terminals: 20 Obsolete: Yes tem Specifications and Additional Information: Wideband FSK Receiver ICs The MC3356 has an Oscillator, Mixer, Limiting IF Amplifier, Quadrature Detector, Audio Buffer, Squelch, Meter Drive, Squelch Status output, and Data Shaper comparator. The MC3356 is designed for use in digital data communciations equipment. Features: - Data Rates up to 500 kilobaud - Excellent Sensitivity: -3 dB Limiting Sensitivity, 30uVrms @ 100 MHz - Highly Versatile, Full Function Device, yet Few External Parts are Required - Down Converter Can be Used Independently Maximum Ratings Power Supply Voltage: 15V Operating Power Supply Voltage Range (Pins 6, 10): 3.0V to 9.0V Operating RF Supply Voltage Range (Pin 4): 3.0V to 12.0V Power Dissipation, Package Rating: 1.25W Junction Temperature: 150°C Operating Ambient Temperature Range: -40° to 85°C Electrical Characteristics:(VCC = 5.0 Vdc, fo = 100 MHz, fosc = 110.7 MHz, ?f = ±75kHz, fmod = 1.0 kHz, 50O source, TA=25°C unless otherwise noted) Drain Current Total, RF VCC and VCC: 20mA typ. Mixer Voltage Gain, Pin 20 to Pin 5: 2.5 min. Mixer Input Resistance, 100 MHz: 260O typ. Mixer Input Capacitance, 100 MHz: 5.0pF typ. Mixer/Oscillator Frequency Range: 0.2 to 150 MHz typ. AM Rejection (30% AM, RF Vin = 1.0 mVrms): 50dB typ. Meter Drive: 7.0 uA/dB typ. Manufactured by: Motorola Part Number: MC3356DW Shipping Item is shipped when payment is received. We ship First-Class and Priority Mail USPS. All items are shipped from Pekin, Illinois. All items are shipped in boxes to protect the product. Box size can vary, but is generally 5in x 2in x 2in to cut down on shipping costs. No item will include insurance unless requested by the buyer. Buyer is responsible for the insurance charges. I do insure items that are worth 20.00 or more and is usually included in the shipping price. We do combine ship. The first item will be full shipping price, then 10 cents for each item after that. Return Policy Returns are accepted as long as the item is returned by the buyer in same condition it was sent. Buyer is responsible for return shipping charges. Buyer will receive 100% of the item purchase price, minus the shipping charges as long as all of these conditions are met. Store Information Binary Electronics has been pleasing customers since August of 2013. We enjoy what we do and our goal is to provide the best customer service as well as service to every single one of our customers. I appreciate the customers we have had since our opening and have helped us grow not only in the areas mentioned above, but business wise too.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Motorola
MPN	MC3356DWR2
Model	MC3356DW
