3pcs Sa56004ed Smbus-compatible, 8-pin, Remote/local Digital Temperature Sensor

US $5.50

Beverly Hills, California, United States
Jan 29th

Open on mobile:
QR code

SA56004ED SMBus-compatible, 8-pin, remote/local digital temperature sensor with overtemperature alarms By NXP The NXP Semiconductors SA56004X is an SMBus compatible, 11-bit remote/local digital temperature sensor with overtemperature alarms. The remote channel of the SA56004X monitors a diode junction, such as a substrate PNP of a microprocessor or a diode connected transistor such as the 2N3904 (NPN) or 2N3906 (PNP). With factory trimming, remote sensor accuracy of ±1 °C is achieved. Undertemperature and overtemperature alert thresholds can be programmed to cause the ALERT output to indicate when the on-chip or remote temperature is out of range. This output may be used as a system interrupt or SMBus alert. The T_CRIT output is activated when the on-chip or remote temperature measurement rises above the programmed T_CRIT threshold register value. This output may be used to activate a cooling fan, send a warning or trigger a system shutdown. To further enhance system reliability, the SA56004X employs an SMBus time-out protocol. The SA56004X has a unique device architecture. The SA56004X is available in the SO8, TSSOP8 and HVSON8 packages. SA56004X has 8 factory-programmed device address options. The SA56004X is pin-compatible with the LM86, MAX6657/8, and ADM1032. Features and benefits Accurately senses temperature of remote microprocessor thermal diodes or diode connected transistors within ±1 °C On-chip local temperature sensing within ±2 °C Temperature range of –40 °C to +125 °C 11-bit, 0.125 °C resolution 8 different device addresses are available for server applications. The SA56004ED with marking code 56004E, and SA56004EDP with marking code 6004E are address compatible with the National LM86, the MAX6657/8 and the ADM1032 Offset registers available for adjusting the remote temperature accuracy Programmable under/overtemperature alarms: ALERT and T_CRIT SMBus 2.0 compatible interface, supports TIMEOUT Operating voltage range: 3.0 V to 3.6 V I?C-bus Standard-mode and Fast-mode compatible SO8, TSSOP8 and HVSON8 packages Programmable conversion rate (0.0625 Hz to 26 Hz) Undervoltage lockout prevents erroneous temperature readings Latch-up testing is done to JEDEC Standard JESD78 which exceeds 100 mA Applications System thermal management in laptops, desktops, servers and workstations Computers and office electronic equipment Electronic test equipment and instrumentation HVAC Industrial controllers and embedded systems TERMS OF SALE We welcome FPO/APO/Military Orders. APO/FPO ships at domestic rates. New Bidders, International bidders welcome - we are flexible on customs declarations. Any questions eoi at lunaticlabs.biz WINDHAGBATS

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	SA5600ED
Brand	NXP
