3pcs Ultrasonic Hc-sr04 Distance Transducer Sensor For Arduino Robot

US $370

  • Shenzhen,Guangdong, China
  • Jun 9th
  This module has been tested in facoty, please buy with confidence. Description: Module main technical parameters: 1.Working Voltage : 5V(DC) 2.Static current: Less than 2mA. 3.Output signal: Electric frequency signal, high level 5V, low level 0V. 4.Sensor angle: Not more than 15 degrees. 5.Detection distance: 2cm-450cm. 6.High precision: Up to 0.3cm 7.Input trigger signal: 10us TTL impulse 8.Echo signal : output TTL PWL signal Mode of connection: 1.VCC 2.trig(T) 3.echo(R) 4.GND Use method: Supply module with 5V, the output will be 5V while obstacle in range, or 0V if not.The out pin of this module is used as a switching output when anti-theft module, and without the feet when ranging modules. Note : the module should be inserted in the circuit before been power, which avoid producing high level of misoperation;if not, then power again. Module Working Principle: 1.Adopt IO trigger through supplying at least 10us sequence of high level signal. 2.The module automatically send eight 40khz square wave and automatically detect whether receive the returning pulse signal. 3.If there is signals returning, through outputting high level and the time of high level continuing is the time of that from the ultrasonic transmitting to receiving. Test distance = (high level time * sound velocity (340M/S) / 2. Note : This module is not suitable to connect with electric power, if you need to connect this module with electronic power,then let the GND terminal of this module to be connected first,otherwise, it will affect the normal work of the module                      Welcome to Horizon_electronic     Although we are new in Ebay,we specialized in international business  for more than 8 years We are professional in international business.      We work with Reliable international post service company.we can make  sure you can get your items in time,     We package every parcel very carefully.We promise you will get your  items in good situation  Mian business  We selling items with high quality and best price . All items will be tested before shipped.  we seek for long term .We mainly selling ICs, electronic component ,  electronic modules. PCB board etc,    We also have customer to find other items that do not selling in our store .pls contact us if you need , we can always provide the best price.    Payment & Return Policy <!--[if !supportLists]-->· <!--[endif]-->We accept Paypal . <!--[if !supportLists]-->· <!--[endif]-->If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback    100% of your money. <!--[if !supportLists]-->· <!--[endif]-->We ensure our products work normally before post.If the products is broken before arrival to you,all you should    do is taking a photo to show us our broken product.We promise to payback 100% of your money. Feedback  We appreciate positive feedback . we always try our  best to service every customer .so if you have ant question ,PLEASE  DON’T HESITATE TO CONTACT  US IMMEDIATEDLY, we are always here to offer help .   Shipping Policy All items will be shipped within 1~2 business day after payment. by China post or Singapore post or HK post,  order more than $25, we provide free tracking number, order less than $25, customer need to  pay $2 if need tracking number ,  Parcel will marked as 'GIFT'  Ship to address provided by  ebay if no special notes from  buyer . Delivery Time: Normally, It Takes About 10-30 Business Days to  Arrival for most Countries. *5-14 days to USA. *10-25 days to Australia / Canada. *14-30 days to major cities in Europe . *4 - 8 weeks to Italy , Brazil ,Russia. However, it may delay due to industrial strike action, severe  weather, custom reasons or peak seasons,  such as Christmas/New Year  Holidays. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand NG
MPN Does Not Apply
Model ELECTRONIC MODULE
