4.4" Lcd Graphic Display Module Data Vision Dg-24064-09 S2rb T6963c Lsi New!

US $7.95

Batavia, Illinois, United States
Jan 29th

Open on mobile:
QR code

LCD DISPLAY MODULE DATA VISION MONO GRAPHIC DG-24064-09 S2RB LCD DISPLAY GRAPHIC LCM DATA INTERNATIONAL CO. LTD. (DATA VISION) DG-24064-09 S2RB 240 COLUMNS X 64 ROWS 0.41 X 0.41 DOT SIZE Overall dimensions: 153MM Wide X 57MM High X 9.5MM (6.02 x 2.24 x .37 inches) Viewing Area: 113mm wide x 31mm high (4.375 x 1.25 inches) SILVER GRAY STN REFLECTIVE POLARIZER MODE VIEW DIRECTION: BOTTOM CONTROLLER LSI: T6963C NEW, ORIGINAL UNOPENED O.E.M. CASES OF 12 (Also available individually) This is the data sheet for the DG-24064-2. The modules we have for sale are DG-24064-09. The differences are: Size: The -09 is 153 x 57 x 9.5 mm Dot size: 0.41 x 0.41 Viewing area: 32 x 112 mm Plastic frame: 46 x 120 mm o.d Additionally, a buyer sent us this information: FYI if You are going to sell more of these nice displays. The display modules I bought are actually better than Your listing suggests. They have in fact on-board Vee supply, no external negative voltage required! Pin20 is not NC as in the pin-out on the listing, it is Vee out. Connect a pot about 10..22k between 20 and Vss, then the moving contact to pin4. MECHANICAL DATA Item Dimension Unit Module Size 180.0(W) x65.0(H) x 10.0(T) mm View Area 132.0(W) x 39.0(H) mm Dot Size 0.49 x 0.49 mm Dot Pitch 0.53x 0.53 mm ABSOLUTELY MAXIMUM RATINGS Item Symbol Standard Value Unit Min Typ. Max. Supply Voltage for Logic VDD- VSS 0 -- 7.0 V Supply Voltage for LCD Drive VDD- VEE 0 -- 28.0 V Input Voltage VI VSS -- VDD V PIN FUNCTIONS Pin No. Symbol Level Function 1 FGND -- Frame Ground (Connected to Bezel) 2 Vss -- Ground Potential (Logic) 3 VDD -- Power Supply For Logic& LCD (+) 4 VEE -- Power Supply LCD (-) 5 WR INPUT Data Write 6 RD INPUT Data Read 7 CE INPUT Clip Enable 8 C/D INPUT Code / Data 9 NC -- No Connection 10 RESET INPUT Controller Reset 11~18 DB0~DB I/O Data Bus Line 19 FS INPUT Font Select 20 NC -- No Connection ELECTRICAL CHARACTERISTICS Item Symbol Condition Min. Type Max. Unit Logic Driver Circuit Power Supply Voltage VDD-Vss -- 4.5 5.5 V LCD Driver Circuit Power Supply Voltage VDD-VEE ¡@ 11.9 12.6 13.2 V Input Voltage VIH Notes(1) 0.7xVDD -- VDD V Input Voltage VIL Notes(1) -- -- 0.3xVDD V Supply Current(Logic) IU IEE IDD=5.0V IEE=-15V -- 5 2.0 mA Power Consumption IDD VDD=0.5V IEE=-15V -- 75 95 mA inkfrog terapeak i000000 inkFrog Analytics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Data Vision International
MPN	DG-24064-09 S2RB
Model	DG-24064-09 S2RB
