4'' Raspberry Pi Lcd Module 320x480 Tft Resistive Touch Display Led Spi For B/b+

US $35.99

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

This auction is for 4inch RPi LCD (A) 4 inch Touch Screen TFT LCD Designed for Raspberry Pi Features Designed for Raspberry Pi Model B/B+, an ideal alternative solution for HDMI monitor IPS technology, high quality and perfect displaying from very wide viewing angle 320x480 resolution Convenient Men-Machine interface for Raspberry Pi, combined with the portable power, DIY anywhere anytime Supports Raspbian system, enables your system to: Play videos (supports multi formats, MP4 and so on) Take photos by touching (up to 17 camera modes) Support software keyboard (system interaction without keyboard/mouse) Key Parameters LCD Type TFT LCD Interface SPI Touch Screen Type Resistive Touch Screen Controller XPT2046 Colors 65536 Backlight LED Resolution 320*480 (Pixel) Aspect Ratio 8:5 Power Consumption TBD Backlight Current TBD Operating Temp. (°C) TBD Photos Interface PIN NO. SYMBOL DESCRIPTION 1, 17 3.3V Power positive (3.3V power input) 2, 4 5V Power positive (5V power input) 3, 5, 7, 8, 10, 12, 13, 15, 16 NC NC 6, 9, 14, 20, 25 GND Ground 11 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching 18 LCD_RS Instruction/Data Register selection 19 LCD_SI / TP_SI SPI data input of LCD/Touch Panel 21 TP_SO SPI data output of Touch Panel 22 RST Reset 23 LCD_SCK / TP_SCK SPI clock of LCD/Touch Panel 24 LCD_CS LCD chip selection, low active 26 TP_CS Touch Panel chip selection, low active External Dimension Package Contains 4inch RPi LCD (A) x 1 DVD x 1 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Touch Screen Type	Resistive
Model	4inch RPi LCD (A)
Touch Screen Controller	XPT2046
Country/Region of Manufacture	China
Aspect Ratio	8:5
Resolution	320x480
