4 Axis Tb6560 Cnc Stepper Motor Driver Controller Board

US $64.89

Shanghai, China
Jan 29th

Open on mobile:
QR code

SKU:flz-120514-007 Features Toshiba TB6560AHQ chip - High power, maximum 3.5A drive current . Professional design, two-stage signal processing, super anti-jamming. 1-1/16 microstep setting - Higher accuracy . Adjustable drive current settings for each axis - 25%,50%,75%,100% of full current can be set for different stepper motors . Overload, over-current and over-temperature safety - Full protection for your computer and peripheral equipment . On board current switching - Power output can be set according to specific user requirement . Relay spindle interface - Outputs Max. 36V 7.5A for spindle motors or coolant pump (only one device can be powered by this output!) 4 channel inputs interface- Can be used for XYZ limit and emergency stop . Bipolar constant current chopper drive with non-resonant region . Full closed-type optical isolation to protect the user's computer and equipment Four control inputs (divided into pairs of knives) - Allows setting of limit and emergency stop. Universal architecture - Supports most parallel software MACH3, KCAM4, EMC2 etc. Specifications: Electrical properties (ambient temperature Tj = 25 °C pm):Input Power: 12-36V DC Stepper motor drive current: 1.5A - 3A/phase Drive type: Double-pole constant flow PWM actuation output Compatible Stepper motors: 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max. Dimensions: 18 * 12 * 4 cm (L*W*H) Please Note Please connect the power supply to the power switch of DC 12-36 V Voltage Selection: > 12-16V DC power supply for Nema 17 stepper motors > 16-24V DC power supply for Nema 23 stepper motors > 24-36V DC power supply for Nema 34 stepper motorsThe power output of 12V shall be applied to the radiator fan of 12V Driver output compatible with 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max. Suitable for unipolar or bipolar stepper motors. Voltage regulated spindle speed controlled by parallel interface as function of supply voltage. Package Includes 1 x 4 Axis TB6560 Stepper Motor Driver 1 x DB25 parallel cable 5 x Wire connectors 1 x CD software (English Manual & Mach 3)
