4 Axis Usb Cnc 6090 Router Engraving Machine Milling Cutting Machine 2200w +rc

US $3,062.00

Leipzig, Germany
Aug 18th

Open on mobile:
QR code

6090 router 4 Axis+2.2kw Spindle motor +VFD +USB Port Metal Wood Engraver with tool sensor X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Description: Router engraving machine parameters: Model: 6090GZ Outside dimension: 1150x970x650mm(LxWxH) Working platform size: 1045x720mm(LxW) Frame Material: The whole machine used 6061 aluminum profiles Max. Feeding height: ≤140mm(From base of Z axis to platform) X, Y, Z Working Area: 600x900x150mm Sliding unit: X axis: SFU1605 Ball Screws; Y axis: SFU1605 Ball Screws; Z axis: SFU1204 Ball Screws Drive unit: X axis: ø20 High intensity round rail; Y axis: SBRø20 high-strength aluminum base rails; Z axis: ø12 high-strength round rail Stepping motor: two-phase 3A (with handwheels) Driving Power for Stepping motor: AC110, Output DC 24V, 10A Maximum Idle speed: 1500mm/m Working Speed: 50-1500mm/min (different material with different speed settings) Spindle motor: 2200Whigh-speed variable frequency spindle motor, ER20 chuck, matching 6mm bur 1Water cooled spindle motor can work longer time than air cooled motor. 2Water cooled spindle motor has higher stability and better concentricity than air cooled motor. Variable-frequency Drive(VFD): AC110V, 2200W, 0-400Hz (built-in Control box ) tips1. The spindle motor must connect with the VFD. 2. It cannot directly connect with the supply voltage (AC110V). 3. Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor.) Drive of Stepping motor0-3.5A adjustable four-axis drive(TB6560AHQchip, 24V power supply, 2, 4, 8, 16 Subdivision settings, Factory setting: 8 subdivided) Repositioning precision: ≤0.05mm Speed: 0-24000r/m Cooling method: Water cooling, Matching heat dissipation water pump Spindle precision: Radial runout≤0.03mm Carving command:G code/TAB file/nc/TAB /NCC/file Protection: Emergency stop button Communication interface: through USB PORT connect with computer Input Volts: AC110V Gross weight of machine:About 145kg/320lb Update function: with limit switch Application industry: Woodworking industry: sculpture, round carving, wooden handicraft processing Advertising signs: logo making, cutting acrylic , plastic molding, suit for making a variety of materials advertising decorative products Other industries: The engraver could do shadow-carved, sculpture which widely used in the gift industry; can be used in aluminum cutting industry,such as aluminum, aluminum-plastic plate, aluminum honeycomb panels, aluminum, 3D engraving process, Artificial plate, cutting LED and neon letter , making plastic light box model; also can engrave on acrylic, copper, PVC board, artificial stone, MDF board, and other metal sheet. Feature: 1. The NEW 2.2KW water-cooled VFD is available operating for long time, which can reinforced the processing ability of the machine and can be used to engrave on aluminum alloy and hard wood. 2. water cooling spindle works more stable and durable. 3. High quality accurate ball Screws drive make the engrving more precision. Anti-blackflash, high precision, long life circle. How to use: 1. Assembling and locating the Engraving machine on steady desk well. 2. Make sure that your computer has a USB port output. 3. Place the control box in a ventilated dry place where there is no dust, no moisture 4. Connecting the control box with the Engraving machine and you computer and make sure the plug will not come off. 5. Correctly connect the machine with the controller. Don't suspended the cable which connect the Spindle motor with axis(X, Y, Z, A). Otherwise, it will damage the driver of the controller. 6. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. 7. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. 10. You can enjoy making you dream with using our Engraving machine now. Package list: 1X main unit (Frame) 1X main unit (working base) 2X Fence baffle 1X control box 1X A axis 1X Sinal cable for A axis 1X pump 1X USB cable 2X cutter 2*6mm 2X cutter 3*6mm 10X 4*7mm round head 6X 4*10mm black Inner six angle screw with nut 8X 5*20mm black Inner six angle screw 4X 5*8mm Flat Philip's head screw with nut and gasket 8X 6*24mm BALCK FLAT Inner six angle screw 12X Aluminium fastener 1X 13-15# Wrench 1X 14-17# Wrench 2X six angle Wrench(3mm) 2X six angle Wrench(4mm) 1X Teflon tape 2X Fuse (5A) 1X Power cable 1X Manual 1x Tools Setting Auto-Check Instrument for Engraving Machine. On Aug-18-21 at 02:11:05 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	shipping notice	Can not ship to Puerto Rico,Alaska/Hawaii
Protection	Emergency stop button
Frame Material	The whole machine used 6061 aluminum profiles
warranty	life-time
Max. Feeding height	140mm(From base of Z axis to platform)
Communication interface:	USB PORT
X,Y,Z Working Area	900(Y)600(X)140mm(Z)
MPN	Does Not Apply
X axis	SFU1605 Ball Screws
Brand	Unbranded/Generic
Y axis	SFU1605 Ball Screws
Outside dimension	1150970650mm(LWH)
Model	6090GZ
Working platform size	1045720mm(LW)
Z axis	SFU1204 Ball Screws
Machine Type	Metal Engraving Machine
Carving command	G code / TAB file / nc file / NCC file
Control	CNC
VFD	AC110V, 2200W, 0-400Hz(built-in Control box
Power Source	Electric
UPC	Does not apply
