4 BABCOCK RELAYS 2PDT: 3 pcs BR7X-300E5 10A, 1 pc BR12-S144 HD-455 3A, Sealed, US $230 – Picture 0
4 BABCOCK RELAYS 2PDT: 3 pcs BR7X-300E5 10A, 1 pc BR12-S144 HD-455 3A, Sealed, US $230 – Picture 0

4 Babcock Relays 2pdt: 3 Pcs Br7x-300e5 10a, 1 Pc Br12-s144 Hd-455 3a, Sealed

US $230

  • Irvine, California, United States
  • Jul 19th
Open on mobile:
QR code
BABCOCK RELAYS  4 Pieces 3 Pieces:  PART NUMBER: BR7X-300E5-26V1 Piece:  PART NUMBER: BR12-S144   HD-455-0018 Hermetically Sealed Can, So no danger of contact sparking  Flange Mounting Tabs These units were carefully removed from an engineering breadboard. They are Fully Tested, see below: Measured Parameters:                       BR7X-300E5-26V      BR12-S144 Unit#                                                  1        2        3           4 ===============                   ==================== Rated Load Current, A                         10      10       10           3 Coil Resistance, ohms:                       299     296     301       683 Voltage Contact Engagement, volts    10.5    10.2      9.6      10.2 Voltage Contact Release, volts              3        4         3            4 I coil at 26VDC, amps                       .081    .084    0.83      .037 Contact Resistance at 1.5A:     NO* pole 1, milliohms                    9          5         4        11     NC pole 1, milliohms                      4          5         5          5     NO* pole 2, milliohms                    7          5         5        19     NC pole 2, milliohms                      6          5         4          7 *applied 26V to coil to close the contacts for measurement Outline Dimensions, inches       Height                                      1.25                             .84       Width (including flange)             1.69                           1.34       Width (excluding flange)            1.06                             .78       Depth                                        .47                             .38       Lead Length                               .19                             .13
“Electrically tested, operation verified, see data below. Exterior condition very good.”
Current Rating 10
Type Power Relay
Model HERMETIC RELAY
MPN BR7X-300E1-26V, BR7X-300E5-26V
Current Type AC/DC
Brand BABCOCK
Number of Poles 4
Application Industrial
Coil Voltage 21-30 V
Country of Manufacture United States
