4 Channels 2gsa/s 100mhz Digital Oscilloscope 7'' Tft Lcd 800x480 Usb Dso7104b

US $750.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you order. DSO7104B Model Channels Bandwidth Sample Rate LCD DSO7084B 4 80MHz 2GS/s 7 inch color DSO7104B 4 100MHz 2GS/s 7 inch color DSO7204B 4 200MHz 2GS/s 7 inch color DSO7304B 4 300MHz 2GS/s 7 inch color DSO7004B Series oscilloscopes cover the bandwidths from 80MHz to 300MHz, and provide the real-time and equivalent sample rates respectively up to 2GSa/s and 25GSa/s. In addition, they have 7 inch color TFT LCD as well as WINDOWS-style interfaces and menus for easy operation. DSO7004B Series oscilloscopes cover the bandwidths from 80MHz to 300MHz, and provide the real-time and equivalent sample rates respectively up to 2GSa/s and 25GSa/s. In addition, they have 7 inch color TFT LCD as well as WINDOWS-style interfaces and menus for easy operation. What’s more, the plenty menu information and the easy-to-operate buttons allow you to gain information as much as possible in measurement; the multifunctional knobs and the powerful shortcut keys help you save a lot of time in operation; the Autoset function lets you detect sine and square waves automatically; the Probe Check Wizard guides you to adjust the probe compensation and set the Probe option attenuation factor. By using the three methods the oscilloscope provides (context-sensitive, hyperlinks, and an index), you may master all operations on the device in quite a short time so as to greatly improve your efficiency in production and development. Oscilloscope Specifications Horizontal Sample Rate Range 2GS/s Waveform Interpolation (sin x)/x Record Length Maximum 32K samples per single-channel; maximum 16K samples per dual-channel (4K,16K optional) SEC/DIV Range DSO7084B DSO7104B DSO7204B DSO7304B 4ns/div to 40s/div, in a 2, 4, 8 sequence 2ns/div to 40s/div, in a 2, 4, 8 sequence Sample Rate and Delay Time Accuracy ±50ppm over any >=1ms time interval Delta Time Measurement Accuracy (Full Bandwidth) Single-shot, Normal mode ± (1 sample interval +100ppm x reading + 0.6ns) >16 averages ± (1 sample interval + 100ppm x reading + 0.4ns) Sample interval = s/div ? 200 Position Range DSO7084B DSO7104B 20ns/div to 80?s/div (-8div x s/div) to 40ms 200?s/div to 40s/div (-8div x s/div) to 400s DSO7204B DSO7304B 2ns/div to 10ns/div (-4div x s/div) to 20ms Vertical A/D Converter 8-bit resolution, each channel sampled simultaneously VOLTS/DIV Range 2mV/div to 5V/div at input BNC Position Range 2mV/div to 200mV/div, ±2V >200mV/div to 5V/div, ±50V Analog Bandwidth in Normal and Average modes at BNC or with probe, DC Coupled 2mV/div to 20mV/div, ±400mV 50mV/div to 200mV/div, ±2V 500mV/div to 2V/div, ±40V 5V/div, ±50V Selectable Analog Bandwidth Limit, typical 20MHz Low Frequency Response (-3db) =20ns) Source Accuracy CH1, CH2 CH3, CH4 0.2div x volts/div within ±4 divisions from center of screen EXT ± (6% of setting + 40mV) EXT/5 ± (6% of setting + 200mV) Set Level to 50%, typical Operates with input signals >=50Hz Note: Bandwidth reduced to 6MHz when using a 1X probe. Video Trigger Type Source Range CH1, CH2, CH3, CH4 Peak-to-peak amplitude of 2 divisions EXT 400mV EXT/5 2V Signal Formats and Field Rates, Video Trigger Type Supports NTSC, PAL and SECAM broadcast systems for any field or any line Holdoff Range 100ns to 10s Pulse Width Trigger Pulse Width Trigger Mode Trigger when < (Less than), > (Greater than), = (Equal), or ? (Not Equal); Positive pulse or Negative pulse Pulse Width Trigger Point Equal: The oscilloscope triggers when the trailing edge of the pulse crosses the trigger level. Not Equal: If the pulse is narrower than the specified width, the trigger point is the trailing edge. Otherwise, the oscilloscope triggers when a pulse continues longer than the time specified as the Pulse Width. Less than: The trigger point is the trailing edge. Greater than (also called overtime trigger): The oscilloscope triggers when a pulse continues longer than the time specified as the Pulse Width. Pulse Width Range Selectable from 20ns to 10s Slope Trigger Slope Trigger Mode Trigger when < (Less than), > (Greater than), = (Equal), or ? (Not Equal); Positive slope or Negative slope Slope Trigger Point Equal: The oscilloscope triggers when the waveform slope is equal to the set slope. Not Equal: The oscilloscope triggers when the waveform slope is not equal to the set slope. Less than: The oscilloscope triggers when the waveform slope is less than the set slope. Greater than: The oscilloscope triggers when the waveform slope is greater than the set slope. Time Range Selectable from 20ns to 10s Overtime Trigger The leading edge: Rising edge or Falling edge; Time Setting: 20-10s Alter Trigger CH1 Internal Trigger: Edge, Pulse Width, Video, Slope CH2 Internal Trigger: Edge, Pulse Width, Video, Slope CH3 Internal Trigger: Edge, Pulse Width, Video, Slope CH4 Internal Trigger: Edge, Pulse Width, Video, Slope Trigger Frequency Counter Readout Resolution 6 digits Accuracy (typical) ±30ppm (including all frequency reference errors and ±1 count errors) Frequency Range AC coupled, from 4Hz minimum to rated bandwidth Signal Source Pulse Width or Edge Trigger modes: all available trigger sources The Frequency Counter measures trigger source at all times, including when the oscilloscope acquisition pauses due to changes in the run status, or acquisition of a single shot event has completed. Pulse Width Trigger mode: The oscilloscope counts pulses of significant magnitude inside the 1s measurement window that qualify as triggerable events, such as narrow pulses in a PWM pulse train if set to < mode and the width is set to a relatively small time. Edge Trigger mode: The oscilloscope counts all edges of sufficient magnitude and correct polarity. Video Trigger mode: The Frequency Counter does not work. Acquisition Acquisition Modes Normal, Peak Detect, and Average Acquisition Rate, typical Up to 2000 waveforms per second per channel (Normal acquisition mode, no measurement) Single Sequence Acquisition Mode Acquisition Stop Time Normal, Peak Detect Upon single acquisition on all channels simultaneously Average After N acquisitions on all channels simultaneously, N can be set to 4, 8, 16, 32, 64 or 128 Inputs Inputs Input Coupling DC, AC or GND Input Impedance, DC coupled 1M?±2% in parallel with 20pF±3pF Probe Attenuation 1X, 10X Supported Probe Attenuation Factors 1X, 10X, 100X, 1000X Maximum Input Voltage Overvoltage Category Maximum Voltage CAT I and CAT II 300VRMS (10x), Installation Category CAT III 150VRMS (1x) Installation Category II: derate at 20dB/decade above 100kHz to 13V peak AC at 3MHz* and above. For non-sinusoidal waveforms, peak value must be less than 450V. Excursion above 300V should be of less than 100ms duration. RMS signal level including all DC components removed through AC coupling must be limited to 300V. If these values are exceeded, damage to the oscilloscope may occur. Measurements Cursors Voltage difference between cursors: ?V Time difference between cursors: ?T Reciprocal of ?T in Hertz (1/?T) Automatic Measurements Frequency, Period, Mean, Peak-to-peak, Cycle RMS, PRMS, Minimum, Maximum, Rise Time, Fall Time, + Width, - Width, + Duty, - Duty, Base, Top, Middle, Amplitude, Overshoot, Preshoot, Pmean, FOVShoot, RPREShoot, BWidth, Delay 1-2 ?, Delay 1-2 ?, LFF, LFR, LRF, LRR, FFR, EFRF Linux Feature Kernel Version Linux2.6.13 Supported File system Yaffs, Fat32 Drivers Buzzer Driver, DMA Driver, FPGA Driver, I2C Driver,SPI Driver, IO-bank Driver, USB Host Driver, LCD Driver, USB massstorage?gadget Driver Linux Applications busybox1.18.4, gnupg1.4.11 U_boot Version Vivi_2.6.13 General Specifications Display Display Type 7 inch 64K color TFT (diagonal liquid crystal) Display Resolution 800 horizontal by 480 vertical pixels Display Contrast Adjustable (16 gears) with the progress bar Probe Compensator Output Output Voltage, typical About 5Vpp into >=1M? load Frequency, typical 1kHz Power Supply Supply Voltage 100-120VACRMS(±10%), 45Hz to 440Hz, CATII 120-240VACRMS(±10%), 45Hz to 66Hz, CATII Power Consumption <30W Fuse 2A, T rating, 250V Environmental Temperature Operating: 32°F to 122°F (0°C to 50°C) Nonoperating: -40°F to 159.8°F (-40°C to +71°C) Cooling Method Convection Humidity +104°F or below (+40°C or below):

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DSO7104B
Channels	4
MPN	DSO7104B
Sample Rate	2GSa/s
Type	Digital
Country/Region of Manufacture	China
Bandwidth	100MHz
