4 Cylinder Internal Combustion Model Engine Plans .pdf

US $40.00

Bismarck, North Dakota, United States
Jan 30th

Open on mobile:
QR code

http://www.burleighmachine.com/index.html This listing is for one set of drawings (Blueprints) for a 4 Cylinder, 4-Stroke, Water Cooled, Spark Ignition, Internal Combustion Engine that can fit in the palm of your hand. This will be in .pdf format, and sent to your preferred e-mail address. There is a total of 32 pages with 30 pages of detailed drawings with machining notes on a few of the pages. I have also included a write-up on making a camshaft the easy way. Once the blank is made, the lobes can be formed in about 20 minutes on the mill, with a rotary table. The plans include drawings for the entire engine, water pump, radiator, fan and carburetor, with a list of references for materials, and notes on starting the engine. There are detailed views of some of the assemblies like the carb, distributor, and water pump. I am confident the engine can be made on small machines like the X2 and Mini Lathe. I am not sure the capacities of the Sherline machines. The biggest limiting factor is the camshaft tunnel, which is a 3/8" hole, 3 1/2" Deep. This could probably be done on a lathe with a clever setup. The largest part is the block which can be made from a 1 3/4" square bar of aluminum 3 1/2" long. A video of the engine running can be found on YouTube at http://www.youtube.com/watch?v=qe2vioXrIKg and http://www.burleighmachine.com/index.html There is a build log of the original prototype at http://www.homemodelenginemachinist.com/index.php?topic=10986.0 I can also send a hard copy of the plans printed on 32lb Glossy 8" x 11" paper through Mail. This option will cost a total of $60. Just let me know of this is what you want. The "Tiny Inline 4" is a 4 Stroke, 4 Cylinder, OHV, Spark Ignition, Splash Lubrication, Water Cooled, Gas engine. It runs on either Gasoline or Coleman Camping Fuel. The bore is .375" and the Stroke is .500". The camshaft has a 260 Degree Duration, and .041" lift. The valves face measure .156" in diameter. This gives it an RPM range of 2500RPM @ Idle, to over 9000 RPM on a free run. This Engine took 7 months worth of "Free Time" from concept to a running engine. Then there was a couple months of refining to get her in good running shape. With the Plans I will have a full year invested in this engine. I have found it to be a good, reliable engine, and to boast a little bit, it was chosen as the "June Project Of The Month" at HomeModelEngineMachinist.com in 2011. The TI4 can be built using small hobby size manual machines, and is designed to use Viton O-Rings for piston rings. It is a great engine for someone with experience in Steam and Stirling engines. The plans were made with the hobby machinist in mind, and would be a great first multi-cylinder IC engine project. The small size keeps cost down. The largest piece is the block which can be machined out of a 1 3/4" Square bar of Aluminum, 3 1/2" Long. The Head is solid brass 3/8" thick, and can be described as nothing more than a rectangular bar with a bunch of holes drilled in it.

Condition:	New: A brand-new, unused, unopened, undamaged item (including handmade items). See the seller's listing for full details. ...	Model	Inline 4 Gas Model Engine Plans / Blueprints
Ages	10 and Up
Brand	Burleigh Machine
Gas, Petrol, 4 Stroke,	Water Cooled, R/C, machinist project
