4 Electro-metrics Antennas: Rvr-25(2), Lpa-25, Tda-25, Tds-25-2, Tri-25 & Tripod

US $510

Kittery, Maine, United States
Jun 21st

Open on mobile:
QR code

Set of 4 Electro-Metrics Antennas: RVR-25(2), LPA-25, TDA-25, TDS-25-2, TRI-25 (Tripod) Condition: Used. Appear to be in good condition. See Photos. RVR 25 Receivers are untested so they are in unknown condition. Electro-Metrics RVR-25 10 KHz to 30 MHz Receiver with monopole antenna and power cable. Also an additional RVR 25 Receiver. Both are in unknown working condition. Electro-Metrics RVR-25 Switchable E Field Rod or Monopole Antenna Base - 10 kHz to 30 MHz for EMI, EMC, and TEMPEST work. Originally configured for MIL-STD testing. The RVR-25 remote/manual Switchable E Field Rod or Monopole Antenna transforms E-fields by switched passive matching circuits from 9 kHz-30 MHz and has been designed for use with the Electro-Metrics EMC-25 and 30 but can be used with other 50 input systems. It covers the same octave ranges as the ten matching bands of the EMC30 Receiver and similar pieces of test equipment. The matching network switches automatically via the ACC-25A/30 control cable connects to the Rx. The use of tuned matching transformers increases the sensitivity of the antenna whilst reducing the risk of overload across the band. It is tuned by means of a controller box (not included) which selects one of 10 different bands. The schematic for the controller box is included. The bands are: 10-35 KHz 35-70 KHz 70-150 kHz 150-250 kHz 250-500 kHz 500-1.1 MHz 1.1-2.4 MHz 2.4-5.5 MHz 5.5-12.4 MHz 12.4-30 MHz Electro-Metrics LPA-25 Log Periodic Antenna. The label has been damaged. Please see the pictures for the label picture. It appears to be the LPA-25 from everything that I can determine. Similar to: EM-6950 (LPA-30 Old Model Number) LOG PERIODIC ANTENNA Features • Wide frequency coverage • High sensitivity • Flat frequency response • Compatible with many measurement instruments Description The Electro-Metrics EM-6950 Log Periodic Antenna was designed to operate over the 200 MHz to 1 GHz frequency range to meet VDE/FCC, military, and other EMI specifications. The broadband frequency capacity of the EM-6950 eliminates the need for band switching, element extension or external tuning when used for EMI ambient surveys or spectrum signature measurements. Applications The EM-6950 is capable of operating either as a transmitting or as a receiving antenna over the frequency range of 200 MHz to 1 GHz. Its linearly polarized design permits separate measurement of horizontal and vertical electric field components over its established range. All-Aluminum construction makes it easily portable and suitable for use in applications where space is limited. The EM-6950 Log Periodic Antenna is fully calibrated and used primarily for radiated emission and susceptibility specification testing. The EM-6950 is capable of operating either as a transmitting or as a receiving antenna over the frequency range of 200 MHz to 1 GHz. Its linearly polarized design permits separate measurement of horizontal and vertical electric field components over its established range. All-Aluminum construction makes it easily portable and suitable for use in applications where space is limited. The EM-6950 Log Periodic Antenna is fully calibrated and used primarily for radiated emission and susceptibility specification testing. Features: Wide frequency coverage High sensitivity Flat frequency response Compatible with many measurement instruments Specifications Electrical Frequency Range: 200 MHz – 1 GHz Input Impedance: Calibrated in a 50-ohm system Average VSWR: <2:1 Maximum Continuous Power: 1000 W Peak Power (short term): 1300 W Output Connector: Type N, female Mechanical Length: 749 mm (29.5”) Width: 749 mm (29.5”) Depth: 63.5 mm (2.5”) Weight:: 1.8 kg (5 lbs.)s.) Electro-Metrics TDS 25 – 2: 500 to 1000 MHz dipole with antennae Electro-Metrics TDA 25: 25 to 200 MHz dipole with antennae Electro-Metrics TRI 25: Wooden Tripod. Similar to EM 6316 Terms and Conditions: An elderly friend is downsizing his ham radio shack. I am helping him do this. As a result, there are no returns on this item. No International shipments. I ship to US only. Terms and Conditions: (once you place a bid, you have agreed to the terms below) This is an Auction - All Sales are Final. You are bidding on only what is in the description and what is pictured in the photos, unless stated otherwise. Everything is described accurately to the best of my knowledge. If you have any questions, ask them before bidding. You are responsible for determining the compatibility of this item and its suitability for your use before you bid. These items cannot be returned. Please read the ad carefully. If you have any questions about this product please contact me, visit the manufacturer's web site or call their customer service before bidding. I will be happy to answer your questions to the best of my ability. Payment must be received within 5 days of close of auction or I reserve the right to void the auction, leave negative feedback and relist the item or offer it to the next highest bidder. I accept only PayPal as payment. I MUST ship to a confirmed address (the same address your credit card bill comes to.) Shipping insurance is included. Pickup is free and available. If your item was damaged in transit, please retain all packaging and contact me as soon as possible so we can file a damage claim with the shipping carrier. If you fail to do this then it may not be possible to get your claim processed. Feedback: I will post positive feedback once I receive positive feedback from you. If you are thinking of posting negative comments or feedback, please e-mail me first and allow me a chance to work with you to satisfy you. Please Email me with any questions. Thank You. Thanks for bidding and good luck
