4 Paellam30 Io Boards For Raspberry Pi - Stm32f303 Arm7 Processor With Usb 2.0

US $99.95

North Vancouver, British Columbia, Canada
Apr 22nd

Open on mobile:
QR code

Overview This auction is for four (4) PaellaM30 boards. PaellaM30 is a high performance IO board for the Raspberry Pi. The onboard STM32F303 processor accepts commands from the Pi that control digital IO, analog output and analog input via the I2C, serial or SPI interface pins of expansion connector P1. PaellaM30 comes pre-programmed with an application to control communication between the Pi and PaellaM30. PaellaM30 brings high speed IO to the Raspberry PI allowing hard real time IO. PaellaM30 has been testing on all available Raspberry PI's. In addition to digital, analog inputs and analog output ports PaellaM30 has two dedicated expansion ports - one accepts the popular RF24L01 wireless transceiver and the other a low cost 128x64 pixel OLED display. Source code is provided to allow control of the wireless module and OLED display. Paella also has a pad for mounting an optional 9DOF MEMs sensor - MPU-9150. Complete source code is provided to acquire MEMs sensor data and output roll, pitch and yaw in real time using a Madgwick filter. Source code is provided to allow custom application development using the CooCox ARM IDE. Download PaellaM Technical Brief (pdf) For information on related products that are compatible with Paella: Pico Family Technical Overview (pdf) for more information on the Pico product family. Nano Family Technical Overview (pdf) for more information on the Nano product family. Differences Between Pico, Nano and Femto Sensor Nodes (pdf) for a description of the differences between SOC Sense modules. Features Fast 72MHz 32bit STM32F303 ARM7 processor with hardware float point processor 256K Flash, 40K SRAM 12bit A/D 4Msps, 12bit 1Msps DAC USB2.0 Interface for standalone, Pi independent, operation 4 USARTS, 2 SPI, 2 I2C, CAN interface Some Digital IO 5V tolerant I2C, USART and SPI interfaces connected between PI and PaellaM On chip DFU boot loader for software field upgrades SPI interface connector for RF24L01 Wireless module Digital and Analog IO brought to connectors Interface connector for direct connection of low cost 128x64 OLED display Real time data acquisition application communicating with PicoM sensor data wirelessly using RF24L01 module MPU-9150 9DOF motion sensor (optional) Source code and project file for CooCox ARM IDE Optional Components A display module is available that directly attaches to the PaellaM30. Check for pricing or purchase directly from third parties. OLED 128x64 display: OLED1 A wireless module is available that attaches to PaellaM30 - the RF24L01 . This module is not included or supplied but is available from third parties. Optional MPU-9150 9DOF sensor available. Warranty PaellaM30 comes with a 60 day warranty and a 7 day return policy. If not completely satisfied simply return the unit in the original packaging for a full refund (less shipping charges). BC customers will be charged 12% (PST+GST) and Canadian customers in other provinces will be charged 5% GST. These are new units direct from the manufacturer and includes warranty and technical support. Note the RF24L01 wireless module, Raspberry PI and OLED display shown in the pictures are not included in the auction. After purchasing, pay instantly with your credit card through PayPal!

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country/Region of Manufacture

Canada
