[4 Pc] Toroid Core, Powdered Iron .94" 24mm, For Power Inductor

US $6.86

Lewis, New York, United States
Jul 5th

Open on mobile:
QR code

Beware of Chinese sellers, especially those who claim "USA Seller" or "Ships from USA". They send Chinese junk to agents in USA for re-shipment to you. Check seller country by clicking on the feedback number and checking the line "Member since..." Toroid-24PI 0.94" Powdered Iron Core Case: Lot Size: 4 units 0.94" Toroid Qty: 4 Powdered Iron Core NOS Arnold Engineering part nr PT940-LL OD: 0.94" (24mm) ID: 0.56" (14.3mm) Height: 0.32" (8.0mm) Magnetic path length: 5.73cm Effective Core Area: 0.374cm^2 Effective Core Volume: 2.14cm^3 Inductance Index: 57.0 nH/N^2 Material: Arnold Mix nr "LL" (low loss) Permeability: 70 +/-10% Grey and blue epoxy enamel coated This material is powdered iron, not ferrite. It is not suitable for transformers, only inductors. It has a distributed air gap inside the core, and thus stores energy (ideal transformer must not store energy). It is suitable for high power filters and chokes, carrying large ripple currents and/or large DC current components, which would otherwise saturate a ferrite core. It is not suitable for transformers in the forward transfer mode, only inductors. OK for FLYBACK transformer ( which is not a real x-former, but a coupled inductor). Not OK for Forward, Push-Pull, Half-Bridge or Full Bridge transformers NOTE: POWDERED IRON IS HEAVIER THAN FERRITE Combined S&H savings on this item is limited by actual USPS chargeable weight I only ship to buyer's EBAY shipping address Purchases can only be changed or cancelled before payment. Best Genuine USA parts from USA distribution. Avoid Chinese counterfeit parts and Chinese seller problems! Transit time 5-7 bus days in USA, however USPS does not guarantee these times, and can exceed them. If you have any time constraints, contact seller before bidding / buying, so we can both come to an agreement. No cancellation possible after Payment. PAYMENT CLOSES ORDER AND COMMITS IT FOR SHIPPING. Your shipping label is created and billed along with insurance the moment you click "PAY". Paypal and insurance charges are non-recoverable. Any returns not resulting from seller wrongdoing will be assessed a restocking fee of 18% and will forfeit shipping costs. International transit times can reach 8 weeks, 10 weeks for Italy and Brazil. You need to contact seller for alternate shipping options at extra cost if this is not acceptable to you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Adams Magnetics
Model	Toroid-24PI4t30
MPN	Toroid-24PI4t30
Country/Region of Manufacture	United States
UPC	Does Not Apply
EAN	Does Not Apply
