4 Spdt Power Relay Module, Omron Relay, 12v Coil, 10a 277vac / 30vdc.

US $170

  • Hong Kong, Hong Kong
  • Jan 29th
Open on mobile:
QR code
  Description 1 Piece Four SPDT Power Relay Module Board. This item has been assembled, and electrical test passed. OMRON G5LA-14  12V Power Relays. LED indicator for each relay channel. BC517 Darlington transistor driving relay, Improve the reliability of action. FR-4 Fiber glass PCB ( Double Layer ). PCB thickness: 1.6mm. Size: 82 x 54.5 x 20mm (approximately  3.23 x 2.15 x 0.79 inch). Power Supply: 12V DC / 200mA (relay all ON). Input control signal voltage:                      0V - 0.5V Low stage (relay is OFF),                      0.5V – 2.5V (unknown state).                      2.5V - 20V High state (relay is ON). Input control signal high state current:                      2.5V: 0.1mA.                      3.3V: 0.18mA.                      5V: 0.35mA.                      12V: 1.1mA.                      20V: 1.9mA. Relay Spec:            Coil: Voltage:  12V DC, Coil Resistance: 400 OHM.            Contact Rating: 277 VAC / 10 Amp or 30 VDC/10 Amp.            Manufacturer: OMRON            Type: G5LA-14  12V DC.            Datasheet: Click here. This is a very simple module board, no paper specifications, any questions, feel free to tell me. Wire connection and PCB size:         VDD: Power supply input,  12V DC.         GND: Power supply ground and control signal ground.          CH_x: Control signal input, Low: relay OFF, High: relay ON.         COM / NO / NC: (C1=COM1, C2=COM2,  C3=COM3, C4=COM4) .                 Control signal state low, the relay OFF, COM - NO disconnected, COM - NC connected.                 Control signal stage high, the relay ON, COM - NO connected, COM - NC disconnected. Schematic (a relay): Engineered for professional eBay sellers!
