4" Z Axis Fast Travel Linear Slide Actuator For Cnc Router, Plasma, Laser

US $225.00

New Hudson, Michigan, United States
Jan 29th

Open on mobile:
QR code

List Price $315 Note: This slide has a 2 start, Fast travel leadscrew IMService 4" travel, Z-slide is ideal for Z axis on CNC machines. Can accept a Nema 23 stepper motor. imsrv.com Ships from stock. Slide has 10 pitch, 2 start acme screw. The acetal antibacklash nut and dual thrust bearings minimize leadscrew end-play and backlash. Assembly includes NEMA 23 motor mount and 1/4 dia shaft, flex coupling. Slide has 16, 8-32 tapped mounting holes. The frame is pre-drilled and tapped for use with V-wheel, rail installations. 4 mounting holes are tapped, and 3 are counter bored for 1/4-20 cap screws. Assembly weighs 4.5 lbs. This Axis will cut up to 150 inches per minute, dry. With light lubrication, it can be used at speeds up to 250-300 inches per minute. Overall thickness of axis, across slide is only 1 7/8 inch ( 1.875). Backplate is 3.5 x 9 inch. Over all length is 11 inches, excluding motor. This Z-slide will mount your spindle very close to the carry axis, for improved ridgidity and reduced chatter when climb milling. To avoid dimensional creep and flexing, this Z-slide does not use any plastic material for the frame or slide components. All structural components are made from precision ground, cast aluminum alloy plate(MIC-6). The aluminum components are all black anodized to prevent corrosion. The anodize coating also provides a hardened surface to guard against surface scratching and denting. The design uses 4 linear ball bearings and 65Rc hardened steel rods to assure a long life and no sag or slop from use of bronze sleeves. If your machine frame is strong enough, this slide can be used for Climb milling. 277 oz-in Bi-polar stepper motor shown is not included, but may be added to the auction for $50 additional, including shipping. Subject to availability. Please check in advance to assure timely shipment with Z-slide. Paypal accepted upon checkout. We will ship this item only to to a confirmed paypal address. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	IMService
Product Type	Linear Slide
MPN	300012
Manufacturer	IMService
Country of Manufacture	United States
Motor Type	Nema 23 Stepper motor mount
Actuator Type	CNC
