40 Hp Application Blower Co Material Handling Blower / Fan Bloapco Model #40-2

US $5200

Saint Paul, Minnesota, United States
May 29th

Open on mobile:
QR code

This blower is in very good working condition.BloApCo model # 40-2 US Motor 40 HP 230/460 volt 3 phase A Oversized Hub B Rotating outlet 360° at 22.5° increments. C Special fan wheel design All-continuous welded construction. Certified, dynamically balanced and stress-relieved. Non-clogging, with flared inlet, tapered fan blade and supporting back plate. D Special heavy-duty blades Angular blade construction adds efficiency. One-piece spider gusset adds strength. E Oversized chrome steel - centerless ground shaft Eliminates shaft deflection under heavy loading. Insures close tolerance between fan shaft, bearings and fan wheel. F Heavy-duty flanged bearings For long life. Heavy surge loading. G Unique shaft mount Allows placement of the bearings close to the wheel and drive pulley, reducing overhung bearing and shaft stress. Details on facing page. H Exterior continuous welded fan housing Provides years of extended trouble-free operation. I Integral fan pedestal/motor mounting Arrangement 9. J OSHA approved belt guard The key to BloApCo efficiency and dependability At the heart of BloApCo design excellence is a unique shaft mount that outperforms and outlasts anything else in the industry. It's a simple fact a fan with a low overhung load performs more smoothly and lasts longer. It all adds up:Pedestal-mounted motor design extends V-belt life, keeping motor and fan shafts in close, rigid relationship. Flanged bearings allow close placement of inside bearing to reduce overhung wheel load. Oversized shaft diameter. Oversized hub. Heavy-duty, long-life bearings. All continuous welded construction. Certified, dynamically balanced fan wheel. Back plate prevents clogging. 4-bolt radial flange bearing provides excellent radial support when fan is conveying heavy offset loads. Pillow block bearings only provide stability in one direction. The 4-bolt flange bearing provides a shaft seal where the shaft passes through the housing. Pillow block bearings cannot provide this seal. BloApCo's low overhung load = low shaft stress & long bearing life Other fans' high overhung load = high shaft stress & short bearing life
