40mhz Dds Function Signal Generator Diy Kit Spi I2c Master Slave Pulse Generator

US $49.90

Hadera, default, Israel
Jan 29th

Open on mobile:
QR code

Hi dear friend, You are bidding for unique high stability, low jitter, high accuracy and low distortion high frequency 0.01HZ - 40MHZ differential / single ended function signal generator diy kit module, which built on DDS (Direct Digital Synthesis) technology. It's ideal equipment for electronic engineer, laboratory, production lines, teaching and scientific research with friendly user interface. Highlights: 1) DDS technology 2) High integrated, multi - module (All in one) system 3) Cost effective 4) Up to 40MHZ sine or square output 5) High stability, Low jitter, Low distortion 6) High resolution and high accuracy frequency programming 7) Continuous Offset and Amplitude adjustment 8) Differential or 2 independent single ended outputs 9) High current drive outputs 10) Sync Out Signal for better synchronization to the external system 11) Ultra high speed SPI and I2C emulator modules 12) High frequency counter 13) Fully adjustable pattern generator 14) Flexible power supply (via 220v - 5v adapter, or direct from PC USB port) 15) Friendly user interface This module includes: 1) 40MHZ DDS function signal generator PCB with all components 2) An AC/DC to USB power converter (220V to 5V) to allow you use power outlet. Kit Features: 1) A custom PCB and all the parts required for a complete build. 2) Assembly drawing, and components (BOM) list for easy kit assembly Requirements: 1) SMD soldering skills and dedicated SMD soldering appliances is needed. 3) Attention to details. Some kit assembly experience is helpful. That equipment has 7 built in modules that mentioned below: 1) Sine wave generator module built in to generate high accuracy, low jitter, high stability and low distortion high frequency sine wave at 0.01HZ to 40MHZ max. frequency range. You can use a differential sine wave output as 2 single ended independent sine wave outputs with common amplitude and offset calibration. That function can replace 2 function generator equipments and to save a cost of 2 function generators. 2) Square (Clock) wave generator module built in to generate high accuracy, low jitter, high stability and low distortion high frequency square or clock wave at 0.01HZ to 40MHZ max. frequency range. You can use a differential clock output as 2 single ended separated clocks outputs with 180 degrees phase shift. 3) I2C analyzer that is ultra high speed unique module, which able to work at Master and Slave modes. It enables full user access to all I2C protocol parameters at both modes. Master mode has write to slave, read from slave and combination (write read) modes. That module able to write and read up to 9 bytes at one transaction. When a transaction is completed, it presents status of transmitted bytes (ACK or NACK) per each byte, and values of received bytes, that was received at last transaction. Slave mode has master to slave write, master from slave read and combination (write read) modes, with write read auto detection module included. It able to read from a master and to write to master up to 9 bytes in one transaction. At the end of the transaction it presents values of all received bytes that was received during last transaction. 4) SPI analyzer that is ultra high speed unique module, which able to work at Master and Slave modes. It enables full user access to all SPI protocol parameters at both modes. That module includes 4 SPI clock polarity modes, input sampling phase calibration (Sampling at middle or end of transaction), MSB LSB bit order change at transmitted and received bytes, and SPI word receive during transmission at Master and Slave modes. SPI module can transmit up to 9 bytes and to receive up to 9 bytes at once. 5) Pulse, Pattern generator module built in to generate pulses trains with user defined parameters. At that module an user can program to output pulses trains with parameters as he wish. That module has built in continuous mode. 6) Frequency counter module built in to measure signal frequencies at the range from 1HZ – 50MHZ. That module has built in auto ranger that can find relevant signal frequency range automatically. 7) Pulse counter module built in to count incoming pulses number. THAT UNIQUE EQUIPMENT HAVEN'T AN ANALOG AT THE MARKET DUE TO IT'S SPECIFICATIONS, FUNCTIONALITY AND FRIENDLY USER INTERFACE. Equipment technical specifications ? Signal Output function Output waveforms Sine wave, Square wave and Triangle wave Output swing 6Vp-p (signal output, no load)(MAX) Output differential swing 12Vp-p (signal output, no load)(MAX) Output single ended impedance 100?±10% Output differential impedance 200?±10% DC offset 2.5V(no load) Display LCD1602 Frequency range 0.01Hz ~ 40MHz (Sine, Square and Clock) 10Hz ~ 100KHz (Triangle and Sawtooth) Resolution 0.01Hz(10mHz) Frequency Stability ±1x10-6 Frequency accuracy ±5x10-6 Sine wave distortion =98% (0.01Hz~10kHz) Rise and fall time of square wave 3ns Square Wave Duty range 40%~99% Sine Wave Jitter (0 – 16MHZ) 80pS Square Wave Jitter (0 – 16MHZ) 80pS Sine Wave Jitter (16 – 30MHZ) 2nS Square Wave Jitter (16 – 30MHZ) 2nS Sine Wave Jitter (30 – 40MHZ) 5nS Square Wave Jitter (30 – 40MHZ) 5nS Square Wave slew rate 400V/uS u I2C function I2C Clock frequency 79KHZ - 10MHZ Master mode support Yes (Read, Write, Combine) Slave mode support Yes (Read, Write, Combine) Automatic Read Write modes detection during scanning at slave mode Up to 9 bytes could be received at one I2C transaction u SPI function SPI Clock frequency 0.625MHZ, 2.5MHZ, 10MHZ SPI Polarity Modes 4 MSB LSB Bit order changing Yes Master mode transmission Up to 9 bytes at one transaction Master mode receive in parallel to transmission Yes Slave mode receive Up to 9 bytes at one transaction u Frequency Counter Function Auto ranger mode Enabled Auto ranger signal search duration 15 sec max. Frequency Meter Range 1Hz~50MHz Frequency meter error less than 1%, above 1KHZ Input Voltage Range 3Vp-p~5Vp-p u Pulse Counter Function Counter Range 0-2100000000 Frequency Meter Range 1Hz~250KHz Input Voltage Range 3Vp-p~5Vp-p u Pulse generator function Output Frequency Range 0.1Hz~20 KHz u Miscellaneous Power in 220V @ 50HZ through included 220v - 5v adapter or through USB cable direct from USB port Power Consumption 100mA from 5v -> 0.5W Dimensions 10 cm x 10 cm x 4.5 cm Current model built without triangle and sawtooth waves, because it is out of stock. IF YOU BID FOR THAT ITEM, I PROMISE THAT YOU WILL NOT BE SORRY. FOR MORE INFORMATION YOU CAN FIND EQUIPMENT USER MANUAL. When you will press that link you will enter to the download site. Please scroll down in the site page until you will see "Click here to start download from sendspace" button. Please press on it and download will be started. That user manual is a function signal generator module equipment manual with all modules inside. Please find relevant chapter of model that you want to bid or you bidded for, at current lot example that is Sine wave output, Square wave output, I2C, SPI, Pulse generator, Frequency counter and Pulse counter chapters, and there you could to impress and to learn about those modules working. IF YOU HAVE A PROBLEM TO OPEN THAT MANUAL, PLEASE SEND ME A MESSAGE VIA EBAY SITE, AND I WILL SEND YOU THAT MANUAL DIRECTLY TO YOUR MAIL. Shipping time 10 - 25 business days. Shipping method is regular mail without tracking number, if you want to ship that item by registered mail with tracking number, please add another 3$ to the item is price. Please attention, a buyer is responsible for border or any additional fees that take affect in his / her country. Have a nice day.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	Israel
DIFFERENTIAL GENERATOR	DIFFERENTIAL GENERATOR
Manufacturer	Board Tech
PATTERN GENERATOR	PATTERN GENERATOR
I2C ENCODER	I2C ENCODER
GENERATOR	GENERATOR
SIGNAL GENERATOR	SIGNAL GENERATOR
ADAPTER	ADAPTER
SIGNAL GENERATOR MODULE	SIGNAL GENERATOR MODULE
I2C ANALYZER	I2C ANALYZER
HIGH FREQUENCY GENERATOR	HIGH FREQUENCY GENERATOR
