450w 12v/24v/36v H-bridge2 Channel Pwm Dc Motor Driver Module Reversing Brake

US $1100

ShenZhen, China
Jun 9th

Open on mobile:
QR code

Description Motor drive module parameters: modular nature:H-bridge DC motor driver module(Suitable for 11-36V DC Motor) Scope:High-power DC motor drive Driving voltage: DC 11-36V Output Current: 15A(Maximum continuous load current 20A) Output Power: max 450W (less than 360W do not need heat sink) Working temperature: 40 ℃ to + 85 ℃ Full load temperature: 45 ℃ Dimensions: 6.6cm × 3.8cm x2.8cm Driver module Product Details: (1) full-bridge driver chip + low-resistance 110A NMOS drive tube to achieve motor brake and reversing. (2) chip operating frequency up to 1MHZ, solve VNH3SP30 MC33886 motor noise and heat problems Japan (3) 2 way PWM inputs in 0-100% duty cycle, (4) applies to lithium battery-powered directly drive (5) built-in logic circuit isolation buffer.Support PLC, directly control of various types of 3V or 5V MCU IO ,By analog voltage input to control the motor brake and reversing. (7) chip built-in hardware dead-time control, (8) chip operating frequency up to 1MHZ, Suitable for Empty harbor motordriving EN: enable terminal PWML1: forward rotation Control PWML2: inversion control GND: power grounding cable Outputs: VIN +: driver board power supply input Positive electrode GND: driver board power supply input Negative electrode M +: connect motor wire M-: connect motor wire Control mode instructions: Electricity Level Control: EN = 0 PWML1 = 0 PWML2 = 1 motor forward running EN = 0 PWML1 = 1 PWML2 = 0 motor reverse running EN = 0 PWML1 = 1 PWML2 = 1 motor brake EN = 1 PWML1 = 1 PWML2 = 1 Motor freedom PWM control mode: EN = 0 PWML1 = duty cycle Adjustable PWM signal PWML2 = 1 motor forward running (changing the duty cycle can speed regulation) EN = 0 PWML1 = 1 PWML2 = duty cycle Adjustable PWM signa motor reverse running (changing the duty cycle can speed regulation) EN = 0 PWML1 = 1 PWML2 = 1 motor brake EN = 1 PWML1 = 1 PWML2 = 1 Motor freedom Package included: 1 PCS x 450W 12V/24V/36V H-Bridge2 Channel PWM DC Motor Driver Module Reversing Brake Shipping Terms 1. WORLDWIDE Free SHIPPING. (Except China) 2. Orders processed within 24 hours of payment verification. 3. We only ship to confirmed eBay addresses. Your eBay address MUST MATCH your Shipping address. 4. The images shown are not the actual item and are for your reference only. 5. SERVICE TRANSIT TIME is provided by the carrier and excludes weekends and holidays. Transit times may vary, particularly during the holiday season. 6. If you have not received your shipment within 30 days from payment, please contact us. We will track the shipment and get back to you as soon as possible with a reply. Our goal is customer satisfaction! 7. Due to stock status and time differences, we will choose to ship your item from our first available warehouse for fast delivery. No Tracking Number The shipping cost is very low,we are not responsible for any loss in the mail if the item not insured(no-registered mail). Registered Post Shipping cost: Would better to Add 3 USD to Upgrade---- Registered Post(Choose "Standard Int'l Shipping" for one item,and others choose free shipping.we can send all your items in one box with tracking number.) Express Courier Need URGENT? We offer a varienty of shipping methods (Expedited Int'l Shipping) to meet your needs.If you need it Urgent, please contact us to Upgrade the shipping to Express. Payment Terms 1.We accept payment via PAYPAL ONLY. 2. Payment must be made within 4 days of auction closing. (Non-payment may result in a UPI (Unpaid Item) being put on your account. eBay will automatically close your account if you accumulate 4 UPI's total.) 3. TOTAL AMOUNT DUE includes the final auction price plus S&H(Shipping and Handling). 4. S&H will be determined based upon the SHIP TO address. PLEASE NOTE: S&H DOES NOT INCLUDE DUTIES, LOCATL TAXES OR ANY OTHER IMPORTATION FEES. 5. Please list your special requests (color, packages, etc.) in the PAYPAL NOTES SECTION when you make payment. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Links for related products 2Pcs L293D L293 L293B DIP/SOP Push-Pull Four-Channel Motor Driver IC $0.99 Shipping:Free Time left:4h 29m ULN2003 Stepper Motor Driver Board Module 5V 12V for Arduino AVR ARM WC $0.99 Shipping:Free Time left:13d 23h 43m Stepper Motor Driver Board Module ULN2003 for 5V 4-phase 5 line 28BYJ-48 $0.99 Shipping:Free Time left:14d 1h 57m L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 top quality $1.19 Shipping:Free Time left:4d 1h 47m NEW EasyDriver Shield stepping Stepper Motor Driver V44 A3967 For Arduino $1.19 Shipping:Free Time left:18d 0h 44m NE555 Frequency Wave Stepper Motor Driver Adjustable Module Duty Cycle Square WC $1.39 Shipping:Free Time left:17d 22h 59m StepStick Stepper Motor Driver A4988 Driver Module For Reprap Prus 3D Printer $1.43 Shipping:Free Time left:5d 9h 9m Motor Driver Controller Arduino HG7881CP Pro DIY H-bridge Stepper Dual DC $1.43 Shipping:Free Time left:20d 2h 25m StepStick Stepper motor driver Reprap Prus A4988 A4983 3D Printer driver module $1.44 Shipping:Free Time left:18d 0h 43m SMD IC DRV8825 DRV8825PWPR stepper motor driver Chip Sop-28 For 3D printer $1.44 Shipping:Free Time left:24d 3h 19m L9110S H-bridge Stepper Motor Dual DC motor Driver Controller Board F Arduino $1.46 Shipping:Free Time left:5h 44m Stepstick Stepper motor driver A4988 A4983 3D Printer driver module Reprap Prus $1.70 Shipping:Free Time left:25d 3h 26m 2pcs ULN2003 Stepper Motor Driver Board Module 5V 12V for Arduino AVR ARM WC $1.84 Shipping:Free Time left:13d 23h 47m 2pcs Stepper Motor Driver Board Module ULN2003 for 5V 4-phase 5 line 28BYJ-48 $1.84 Shipping:Free Time left:14d 1h 57m Arduino DRV8825 stepper Motor Driver Module 3D printer RAMPS1.4 RepRap StepStick $1.86 Shipping:Free Time left:20d 4h 29m 5Pcs L293D L293 L293B DIP/SOP Push-Pull Four-Channel Motor Driver IC $2.24 Shipping:Free Time left:4h 29m Stepper Motor Driver IC TB6560AHQ ZIP-25 for TOSHIBA NEW $2.38 Shipping:Free Time left:15d 23h 55m 2PCS L9110S H-bridge Stepper Motor Dual DC motor Driver Controller Board $2.45 Shipping:Free Time left:5h 44m 2Pcs L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 top quality $2.45 Shipping:Free Time left:4d 1h 47m 2PCS NEW Easy Driver Shield stepping Stepper Motor Driver V44 A3967 For Arduino $2.59 Shipping:Free Time left:20d 4h 32m Microstepping DMOS Motor Driver A3977 A3977SED A3977SEDT $2.69 Shipping:Free Time left:1d 6h 13m 2pcs HG7881CP H-bridge Stepper Motor Dual DC motor Driver Controller Board $2.76 Shipping:Free Time left:20d 2h 29m 2pcs SMD IC DRV8825 DRV8825PWPR stepper motor driver Chip Sop-28 For 3D printer $2.88 Shipping:Free Time left:24d 3h 19m 2pcs NE555 Frequency Wave Stepper Motor Driver Adjustable Module Square $2.90 Shipping:Free Time left:10d 5h 0m 5pcs ULN2003 Stepper Motor Driver Board Module 5V 12V for Arduino AVR ARM WC $2.93 Shipping:Free Time left:13d 23h 42m 2PCS StepStick Stepper Motor Driver A4988 Driver Module For Reprap 3D Printer $3.05 Shipping:Free Time left:5d 8h 53m 2PcsStepStick Stepper motor driver Reprap A4988 A4983 3D Printer driver module $3.14 Shipping:Free Time left:27d 2h 32m New TB6612FNG Dual Motor Driver Module for Arduino STM32 ARM Replce L298N $3.46 Shipping:Free Time left:24d 1h 20m 10Pcs L293D L293 L293B DIP/SOP Push-Pull Four-Channel Motor Driver IC $3.77 Shipping:Free Time left:4h 29m PCA9685 16-Channel 12-bit PWM Servo motor Driver I2C Module For Arduino Robot $3.87 Shipping:Free Time left:26d 6h 18m I2C IIC control H-Bridge DC Motor Driver Moto Shield DRV8830 Module F Arduino WC $3.97 Shipping:Free Time left:10d 3h 29m 5pcs Stepper Motor Driver Board Module ULN2003 for 5V 4-phase 5 line 28BYJ-48 $3.98 Shipping:Free Time left:14d 1h 56m 2PCS Arduino DRV8825 stepper motor driver Module 3D printer RepRap StepStick $4.02 Shipping:Free Time left:20d 4h 29m Dual Channel Motor Driver Shield L298P DC Stepper Driver Board For Arduino WC $4.23 Shipping:Free Time left:27d 5h 58m 2Pcs Microstepping DMOS Motor Driver A3977 A3977SED A3977SEDT $4.55 Shipping:Free Time left:1d 6h 13m Mini 30A VNH2SP30 Stepper Motor Driver Monster Moto Shield module For Arduino $4.60 Shipping:Free Time left:7d 5h 17m ORIGINAL TOSHIBA TB6600HG Stepper Motor Driver controller IC ZIP-25 $4.71 Shipping:Free Time left:2d 5h 41m NEW High-Current MOSFET Switch Module DC Fan Motor LED Strip Driver Steples $4.78 Shipping:Free Time left:6d 10h 14m A4988/DRV8825 3D Printer Stepper Motor Driver Control Extension Boards $4.83 Shipping:Free Time left:22d 5h 53m 2PCS Stepstick Stepper motor driver A4988 A4983 3D Printer driver module Reprap $4.89 Shipping:Free Time left:25d 3h 26m 5Pcs L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 top quality $4.97 Shipping:Free Time left:4d 1h 47m L298P Shield R3 DC Motor Driver Module 2A H-Bridge 2 way For Arduino UNO 2560 WC $5.43 Shipping:Free Time left:7d 0h 1m 2PCS Stepper Motor Driver IC TB6560AHQ ZIP-25 for TOSHIBA NEW $5.51 Shipping:Free Time left:15d 23h 55m Dual channel Motor Driver Shield L298P DC stepper motor driver board For Arduino $5.54 Shipping:Free Time left:1d 6h 23m Stepper Motor Driver Controller Shield +StepStick Driver A4988 for 3D printer W $5.89 Shipping:Free Time left:28d 3h 30m 5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3 $6.10 Shipping:Free Time left:13d 4h 57m 5PCS NEW Easy Driver Shield stepping Stepper Motor Driver V44 A3967 For Arduino $6.12 Shipping:Free Time left:20d 4h 32m 5PCS L9110S H-bridge Stepper Motor Dual DC motor Driver Controller Board $6.46 Shipping:Free Time left:1d 5h 2m
