4g/3g/2g/gsm/gprs/gnss Hat For Raspberry Pi Lte Cat4 Global Version

US $78.74

Swanton, Vermont, United States
Aug 10th

Open on mobile:
QR code

Description 4G/3G/2G/GSM/GPRS/GNSS HAT LTE CAT4 Global Version Designed for Raspberry Pi (Not included) Offers 2x LED indicators for easy monitoring of working status Provides USB to UART converter and breakout UART control pins Onboard audio jack and audio decoder for making a telephone calls Operates at 3.3 or 5 V voltage Comes with development resources and manual The 4G/3G/2G/GSM/GPRS/GNSS HAT for Raspberry Pi LTE CAT4 Global Version supports LTE CAT4 up to 150 Mbps for downlink data transfer. Has a pretty low power consumption. You can connect this 4G module with a computer to surf the Internet or attach it onto Raspberry Pi to enable functions like 4G high-speed connection, wireless communication, making telephone calls, sending SMS, global positioning, etc. Note: the Raspberry Pi in the photo is NOT included. Specifications Power supply: 5 V Operating voltage: 5 V / 3.3 V (configured via jumper) Operating temperature: -30 ~ 80 °C Storage temperature: -45 ~ 90 °C Weight: 0.25 kg Receiver type 16-channel C/A code Sensitivity Tracking: -159 dBm (GPS) / -158 dBm (GLONASS) / TBD (BD) Cold starts: -148 dBm Time-To-First-Fix (open-air) Cold starts: <35 s Hot starts: <1s Accuracy Position: <2.5 m CEP SMS Supported types: MT, MO, CB, Text, PDU Storage: USIM card and ME (default) Audio feature Supports echo cancellation Supports noise reduction What's Included 1 x SIM7600G-H 4G HAT 1 x LTE Antenna 1 x GPS External Antenna (B) 2 x USB type A plug to micro plug cable 1 x RPi screws pack (2pcs) Dimensions Size 56.21 x 65.15 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
MPN	17372
Type	Waveshare
UPC	Does not apply
