4pcs 52 Blade Thread Gauge Kit 55°&60° Inch Centre Gage Metric Durable

US $14.14

suzhou, China
Aug 12th

Open on mobile:
QR code

Product Description 4Pcs 52 Blade Thread Gauge Kit 55°&60° Inch Centre Gage Metric Durable Features: 100% brand new and high quality Made of high-quality materials, durable The thread pitch gauge is used to measure the thread pitch. It is equipped with 4 center gauges, 55° inch and 60° metric. Center gauges are used to grind and position thread cutting tools on a lathe. Usually used to check the thread size to determine whether it is correct. Made of stainless steel, it is not easy to rust. Ensure the accuracy of the measurement. There are 24 sheets in the metric system, and the pitch of each sheet is 0.25-6mm. There are 28 pieces in inches, and each piece is represented by the number of teeth per inch from 4-62 teeth. Can be used to measure metric and inch threads. The blade can also be used to measure AF threads per inch of thread. Product parameters: Type: Thread gauge Material: Stainless steel Color: silver Measuring system: metric system, imperial system Quantity: 52 how to use 1) Measure the pitch Use the thread pilot group as a template to clamp the toothed steel threads on the tested workpiece. If they are not close together, the other is one until they fit together. Then marked on the thread size model is the measured thread pitch of the workpiece. 2) Measure the tooth profile angle Put the thread pitch and the measured workpiece thread model on the same thread for testing, and then check the Thalia contact. If there is no translucent gap, it is correct to measure the thread profile angle. If there is unevenness in the light transmission gap, it means that the measured thread profile is not accurate. There are 24 pieces in the metric system. The pitch of each piece is 0.25-6mm. The number of pitches is: 0.25/0.3/0.35/0.4/0.45/0.5/0.6/0.7/0.75/0.8/0.9/1.0/1.25 / 1.5/1.75/2.0/2.5/3.0/3.5/4.0/4.5/5.0/5.5/6.00 There are 28 pieces in one inch, and each piece is represented by the number of teeth per inch from 4-62 teeth, especially as the number of teeth: 4/4.5/5/6/7/8/9/10/11 /12/13/14 /16/18/19/20/22/24/25/26/30/28/32/36/40/48/60/62 Package list: 1 *52 blade thread gauge 1 *ISO Metric 60° Centering Gauge Thread Gauge Tool 1 *Inch Wyeth 55° Centering Gauge Thread Gauge Tool 1 *American Standard 60° Centering Gauge Thread Gauge Tool Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Material	Stainless steel
MPN	Does Not Apply
Color	silver
Gage Type	Thread Gage
Quantity	52
Package Contents	52 blade thread gauge kit
UPC	Does not apply
