5 Ghz Pll Brick Oscillator, 12.3 Dbm Output

US $280

  • San Marino, California, United States
  • Feb 12th
Open on mobile:
QR code
4.8--5.3 GHz PLL brick oscillator by Loral, model MS-51X.   Contains a high-Q cavity oscillator (adjustable via the CAVITY TUNE screw) that is phase locked to a harmonic of the internal non-ovenized crystal oscillator.  Here, I am using a XTAL of 100 MHz, cavity oscillator runs at 1300 MHz, and the multiplier block is X4 giving 5200 MHz output.  The output power at the female TNC connector is 12.3 dBm.   Requires a well-regulated  +20.0 VDC supply (not -20 VDC as is indicated on the front of the brick).   The spectrum analyzer (at 1 MHz/div), cables, attenuators, are not included in auction.  The 100 MHz HC-49 crystal is included.  This "brick" is in nice clean condition, and it phase locks just fine.  Ships to USA for $8.00 via USPS Priority mail in antistatic bag, well packed, and boxed.   No shipping out of USA.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Loral
Model .MS-51X
