5 Pcs Drv8825 Stepper Motor Driver Control Extension Shield Board For 3d Printer

US $14.85

suzhou, China
Jul 22nd

Open on mobile:
QR code

Product Description 5 Pcs DRV8825 Stepper Motor Driver Control Extension Shield Board For 3D Printer Product description: 100% brand new and high quality Made of high-quality materials, durable The DRV8825 stepper motor driver carrier is the breakout board for TI's DRV8825 microstepping bipolar stepper motor driver. This module has almost the same pins and interfaces as our A4988 stepper motor driver carrier, so it can be used as a higher performance direct replacement for these boards in many applications DRV8825 has adjustable current limit, overcurrent and overheat protection, and six microstep resolutions (down to 1/32 step) Its operating voltage is 8.2 – 45 V, and each phase can provide up to approximately 1.5 A of current without the need for a radiator or forced air (the rated current of each coil is up to 2.2 A, and there is sufficient additional cooling) Simple step and direction control interface Six different step resolutions: full step, half step, 1/4 step, 1/8 step, 1/16 step and 1/32 step Can directly interface with 3.3V and 5V systems Over-temperature thermal shutdown, over-current shutdown and under-voltage lockout Short-to-ground and load short-circuit protection 4-layer 2 oz copper PCB for improved heat dissipation Exposed solderable ground pad under the driver IC on the bottom of the PCB The module size, pinout and interface match our A4988 stepper motor driver carrier in most aspects Adjustable current control allows you to use the potentiometer to set the maximum current output, allowing you to use a voltage higher than the rated voltage of the stepper motor to achieve a higher step rate Intelligent chopper control, automatically select the correct current attenuation mode (fast decay or slow decay) 45 V maximum supply voltage Built-in voltage regulator (no need for external logic voltage supply) Package list: 5 *DRV8825 stepper motor driver 5 *Radiator Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Package Contents	5 DRV8825 stepper motor driver+5 Radiator
Brand	unbranded
UPC	Does not apply
