5amp Adjustable Voltage Regulator Board, External Pot. Sku160003

US $4400

  • Hong Kong, Hong Kong
  • Jan 29th
  Description This item has been assembled, and electrical test passed. 5 Amps voltage regulator module, based on National Semiconductor LM338T regulator IC design, AC or DC input, DC output, output voltage LED indicator. Used high-quality electronic components: Thickness 1.6mm FR-4 fiber glass PCB (double layer). HQ terminal blocks easy connection wire. 4700uF/50V input and output filter capacitors, 100nF/100V metal film capacitors, conducive to filtering high-frequency noise. External potentiometer, wire length 300mm. LM338T IC Datasheet: http://www.national.com/ds/LM/LM138.pdf Module Specification:  http://www.audiowind.com/pdf/A-210EP.pdf,  No paper specifications, please download this document. Input voltage:DC 4 - 35V, or AC 4 - 26V. Output adjustable range: 1.5 - 32V DC. Maximum continuous output current: 5 Amps. Module size: 80 x 76.2 x 55 mm (L x W x H)                        3.15 x 3 x 2.2 inch (L x W x H) Schematic: PCB Size and wiring diagram: PCB Layout (double layout): eee SKU160003 Your partner for managing your online business
