5pcs 2.4g Nrf24l01+ Rfid Wireless Transmission Module 2dbm 1mw 2.4ghz

US $13.65

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: 5pcs 2.4G nRF24L01+ RFID Wireless Transmission Module 2dBm 1mW 2.4GHz More Items In Our Store,Click Here! SKU: 4620*5 Parsts No. : Package: Brand: Quantity: 5 2.4G nRF24L01+ RFID Wireless Transmission Module 2dBm 1mW 1. Basic information: Model: E01-ML01S Center frequency:2.4GHz measured distance:90m max power :1mW component source: imported components Features:Small volume, excellent performance 2.Products 3. performance parameters: Module Size:11.8*18.7mm interface method:1*8*1.27mm(can use universal board or Dupont Line) Power Supply:1.9V——3.6VDC Measured distance:90m Communications levels:0.7VDD——5.2VDC Maximum power:0dBm(about 1mW) Gbps:250k,1M,2M, Adjustable Emission current:11.3mA Sinks current:13.5mA Communication interface:Standard SPI mode Transceiver length:single packet:1—32 bytes,3 FIFO buffer RSSI support: Does not support the true meaning of RSSI,Only supports packet loss statistics Working temps:-30°C~+85°C Working Humidity:10%— 90% RH Storage Temp:-40°C~+125°C Operating frequency:2400MHz-2525MHz(1MHz step ,Through software control) Receiving Sensitivity:-94dBm @ 250Kbps 4. Pin Definitions: Name Direction Use 1 VCC power pin,Must be1.9 - 3.6V 2 CE Input Control module pin 3 CSN Input Module chip select pin,To start a SPI communication 4 SCK Input The SPI bus clock 5 MOSI Input Module SPI data input pin 6 MOSI output Module SPI data input pin 7 IRQ output Module interrupt signal output, active low 8 GND Ground, connected to the power supply the reference 5. Circuit diagram: For more quantity, please contact me.(My skype: ada-yu2013) The Standard shipping we provide is non-regiested mail without a tracking. We provide free shipping with tracking number when your order is over $50. If your oder is below $50 and you need tracking, please contact me. Maybe you request 10Pcs 2.54mm 40Pin Single Row Right Angle Pin Header Strip new 10pcs 2x20 Pin 2.54mm Double Row Right Angle Female Pin Header new 10pcs breakable pin header 40 Pin 1x40 Male 2.54 NEW 10pcs 2.54mm Pitch Dual Row 5 x 2 ISP Download JTAG I/O Socket DIY DC3-10P New 10pcs NEW 40Pin 1*40 2.54mm 20mm Long Header Pin Male Breakable Pin Header $ 2.36 + free shipping $ 3.69 + free shipping $ 1.08 + free shipping $1.14 +free shipping $ 2.43 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
