5pcs 4-channel Control Voice Sound Record Playback Module 0.3ma For Arduino

US $22.95

  • Shenzhen, China
  • Feb 21st
Open on mobile:
QR code
Product Name: NEW ICSH030A 4-Channel Control Voice Sound Record Playback Module for Arduino More Items In Our Store,Click Here!   SKU: 5237*5 Parsts No. : Package: Brand: Quantity: 5   4-Channel Control Voice Sound Record Playback Module Features - Amplifier board module, the maximum output power2.5W, loud and clear voice. - Volume adjustment function, the volume can be change according to the Requirements. - New circuit, strong anti-interference ability. - Smaller size: 16mm*18mm. - SupportMono 8 bit 8K and 16K sampling rate, the sound can have arbitrary segments, each sound segment can have arbitrary length. - Voice information can be recorded and broadcast as different segments , the voice information can be changed at any time. - FLASH memory. Lower cost and better reliability. - New standby mode and the its working current is just 0.3mA. Pin Map NUM Label Function Remarks 1 VCC Power+(4.75~12V)   2 TXD/D4 Serialport Tx and control pin 4   3 RXD/D3 Serialport Rx and control pin 3   4 D2 control pin 2   5 D1 control pin 1   6 GND Ground   7 VO- Voice volumeoutput +   8 VO+ Voice volume output-   9 OUT Voice without power amplification   10 NC No connect   11 BUSY (Working mode) high level when in play mode.   12 MODE Mode selection:High:play mode;low:record mode Record Mode Method Please refer to the introduction of the “ICWaveDownload” Play Mode Method Schematic diagram Module response to rising edge of pins D1,D2,D3,D4. (Frequency:about 50Hz). Mechanical drawing The mobile Application Arduino control   Access control system     Any problem, please contact us freely       1) We accept PayPal payment ONLY.     inkFrog Analytics On Jul-25-14 at 21:35:08 PDT, seller added the following information: On Feb-08-15 at 21:06:10 PST, seller added the following information:
