5v-30v Pulse Signal Cycle Time Delay Timer Switch Fet Mos Control 0.1sec~999min

US $8.99

  • HONG KONG, Hong Kong
  • Jun 9th
Welcome to my ebay store! You will find your favorite products. Pass by do not miss.thank you! Product Detail This product is unique advantages: 1, to achieve high-frequency fast frequent on-off circuit. 2, on-off process does not produce noise. 3, there is no spark. 4, there will be no electromagnetic interference. 5, long life than conventional electromagnetic relay life. Often used to control motors, light bulbs, LED lights, DC motors, miniature pumps, solenoid valve.   Specifications:    1: Size: 64.2mm * 39.5mm * 13mm 2: Output capacity: DC 5 ~ 30V DC maximum current: 20A is greater than the need to add heat sink 5A 3: Quiescent Current: 20mA Working Current: 50mA 4: Operating Voltage: DC DC 5 ~ 30V (common universal operating voltage 9v 12V 24V) Signal voltage: DC DC4V ~ 27V (common power supply positive trigger, or button, PNP sensors, PLC signals, etc.) 5: life: unlimited switch Operating temperature: -40 ~ 85'C 6: the use of opto-isolated input and output, enhanced anti-jamming capability power, ensure stability, industrial grade board, class PLC, after setting the parameters of power and can never remember, the signal terminal voltage signal can be maintained for a long time. 7: Delay time can adjustable ,When decimal point is behind third digit, time setting is 0-999 minutes. When it is behind the second digit, 0-99.9 seconds. When there is no decimal point, the time range is 0-999 seconds. customers can easily switch time range and size, power saving Delay time of the last set, without duplication.   Board Features: 1, The output signal is triggered to work, time to stop working during the delay A: Again trigger invalid B: trigger again restarts the timer C: trigger again to stop the timer reset termination; 2, The signal triggers the beginning of counting time T1, T2 time to work off the output (reset) T1 and T2 times are adjustable; 3, Recycling: ON T1, disconnect T2, infinite loop. T1 and T2 times are adjustable; 4, One signal, output work, keep working, the signal disappears, start time, time is up, the output stops working, during the delay, again to the signal delay cancellation signal disappears, re-timing.   Working mode selection: When powered, long press K1, 2 seconds later enter the selection function mode, P1-1 ~ P1-4 Alternatively.   P1-1 mode: trigger output signal work, time is up, the user can set the time to stop the work output of T, press the K2 hundred digit LED starts flashing, then press K3, hundreds digits change; click on K2 ten digital start flashing, then press K3, ten digit change; click K2 bit digital tube starts flashing, then press K3, single-digit change; press the K2,; digital pipe no longer flashes , then press K3, shifting the decimal point, the decimal point in a bit indicates 0-999 minutes in 10 bit from 0 to 99.9 seconds with no decimal point indicates 0-999 seconds; select good, now the time setting is completed. Short press K1, enter the function of fine-tuning settings, trigger the default delay period is invalid, press K1, during the delay trigger valid (again time), press K1, during the reset delay (timing is off, output reset) Press again to repeat the default settings for the first time.   P1-2 mode: The signal triggers the beginning of time to the output timing X Y disconnected. Users can set the delay time to wait and work time X Y; P1-1 different time settings similar blue light indicates the set working hours, blue light off indicates setting time waiting for work. Short press K1, enter the function of fine-tuning settings, the default trigger delay period is invalid, press K1, during the delay trigger valid (again time), press the repeat first default settings.   P1-3 mode: ON X seconds, disconnect Y seconds, an infinite loop. Users can set the time to stop and work time X Y; time setting similar to P1-2. Short press K1, enter the function of fine-tuning settings, first turn on X, Y seconds off, press the K1, first disconnect the X, Y seconds ON ,, press the repeat first default settings.   P1-4 mode: trigger output signal work but do not start the timer, the trigger signal disappears start time T, time is up, the output is disconnected; During the delay, again to the signal delay cancel, keep working (on), signal disappears, restart timing; (equivalent to release button to start timing, commonly used in the power-off delay). Users can set the output working time T; the time setting is similar to P1-1.   Package Included: 1x 5V-30V Pulse Signal Cycle Time Delay Timer Switch   Feedback > We maintain hightest buyer ratings > Positive Feedback will be much appreciated from you. > Any dissatisfaction, please contact us immediately! > Please do not leave neutral or negative feedback before we help you out. Payment > We accept PayPal only. > All major credit cards are accepted through secure payment processor PayPal. > Payment must be received within 7 days of auction closing. Shipping > We Ship to Worldwide, except Hong Kong, Nigeria..... > Items will be shipped within one business day on payment received. > Items are shipped from China using Airmail, delivery time depends on destination and other factors,reach most of the countries within 10 to 35 business days. Country Shipping Way Shipping Time Tracking Number United States            China Post   7-12 Yes Russian China Post 15-35 Yes Other Country HK /Swiss Post Air Mail 15-45 No Brazil / Africa HK /Swiss Post Air Mail 35-65  No  Returns > Defect: We will fully refund or send you a new replacement,please contact and return within 14 days. > Dissatisfaction: Please contact within 3 days, we will fully refund, after got your returned goods. > Missing parts/Q'ty: Please contact us immediately,for a new package arranged,or a partial refund issued. Contact us > If have any question, Please contact us by ebay message before leaving neutral, negative feedback or open any dispute, we will reply within 24hours, ensure that help you solve the problem, make you satisfied. > Our Working-time From 8:30 AM to 21:30 PM(GMT+08).
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand DIY
Working votage 5-30V
MPN DIY
Working current max 20A
Time adjust 0.1s~999m
UPC Does not apply
