5w Dc Dc Converter Module Step Up Boost Usb 5v To 12v For Mobile Power Led Wifi

US $72

Guangzhou, China
Apr 23rd

Open on mobile:
QR code

Below item is powered by Canton-electronics Ltd. Product Name: 5W DC DC Converter Module Step Up Boost USB 5V to 12V for Mobile Power LED Wifi Module No.: CE017 buy it now,from here!!! Packing list: 1 pcs USB to xh2.54 DC DC Converter boost module(input DC 3-6V , output DC 12V) ; 1pcs XH2.54 2 Pin Power Cable Description: You can buy it now,from here!!! Input voltage 3~6V, output 12V (+-5%) Maximum input current : 1.2A Long-term work Current : 1A Conversion efficiency : 78-90% Start Voltage 2.8V, Output Current 50MA INPUT 3V 1A; OUTPUT 12V 200MA INPUT 3.3V 1A; OUTPUT 12V 245MA INPUT 3.7V 1A; OUTPUT 12V 280MA INPUT 4.5V 1A; OUTPUT 12V 340MA INPUT 5V 1A; OUTPUT 12V 370MA INPUT 6V 1A; OUTPUT 12V 450MA DC-DC Boost Step Up module working frequency 1.0MHZ. Operating ambient temperature : -20~+85 Degrees Celsius .Size 42mm x 15mm x 5.6mm(small) Weight : about 5.6g(light) Applications: 12V Low Power Motor 12V Low Power Fan 12V LED Lighting 12V Relay board 12V Wifi Router Wireless communication equipment 315M 433M Wireless remote controller Attention : This is a DC-DC voltage converter module,Must be noted when using: 1 Input voltage can not be greater than the maximum input range 2 Output power can not be greater than the maximum load for a long time 3 Input power must be greater than the output power, because the power consumption of the module itself Modify Parameter Description: 1.2A current limiting resistor,Remove the resistance, the maximum input current can reach 2A. But IC have "Over Temperature Protection" Function.It will turn off the power MOSFET automatically when the internal junction temperature is over 150 Degrees Celsius. The power MOSFET wake up when the junction emperature drops 30 Degrees Celsius under the OTP threshold temperature The master chip is FP6291GLR ★Introduction for Shenzhen Canton-electronics Trading Co.,Ltd : We specialize in RF Wireless Radio Transmitting Units and Receiving Units, the product include transmitters with case, receivers with relay(s), transmittng modules and receiving modules, are widely applied in RC toy, remote sensing, telemetry, fireworks, industrial control, home&garden application. ★Shipping: Normally shipping is by Airmail from China Post Air Mail or Hong Kong Post Air Mail ,15-60 days shipping time based on different country . Express is available, shipping time is 2-7 days all over the world, and telephone number is needed. Please contact us first for extra payment . ★Benefits The Best Prices. By working with Canton-electronics Ltd, you can take advantage of the internet business, cut off the wholesalers cost and other costs, and import your products directly from the manufacturer at incredible prices. Prompt Delivery. Most units are in stock all the time, standard units will be completed within 1-3 days if they are sold out, it is great help for you if your project must be completed before deadline. Prompt Service. Mails will be replied within 24 hours We work 6 days a week. ★Return Policy All mails will be replied to within 24 hours except on weekend and holidays. Every item is manufactured under Strict Quality-Assurance Guidelines. If you are dissatisfied for any reason, please return the product to us, and we'll refund your money(not including shipping fees). Please ensure that return items are not used. Return items must be Posted within 7 days of receipt. Please inform us via email before posting your return package. ★PAYMENT •We accept PayPal only. •We only ship item to your PayPal verified address. •Payment must be received within 3 Days from the date of purchase. •Please leave note in PayPal when making the payment if you have any special request (colors/size). Orders will be processed instantly and dispatched in same day normally, so we do NOT accept any Email/Message note before or after you place orders. ★Import tax : We will dispatch the item as SAMPLE or GIFT , label the total amount on the custom declare invoice . Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. Please check with your country’s customs office to determine what these additional costs will be prior to buying. Engineered for professional eBay sellers!
