5x Cobalt Amorphous Core Toroid Transformer Inductor Choke MSF-20A-T 22.5mm 120?, US $150 – Picture 0
5x Cobalt Amorphous Core Toroid Transformer Inductor Choke MSF-20A-T 22.5mm 120?, US $150 – Picture 0

5x Cobalt Amorphous Core Toroid Transformer Inductor Choke Msf-20a-t 22.5mm 120?

US $150

  • Moscow, default, Russian Federation
  • Mar 6th
Open on mobile:
QR code
Cobalt Amorphous Core Toroid MSF-20A-T in hard plastic protective container of glass-polyamide and mechanically fixed with silicone sealant. MSF series toroidal magnetic cores are made of thin (25 microns) Co-based amorphous ribbon with flat hysteresis loop have high permeability and very low losses. The container has rounded edges and is designed for direct winding of a thick wire. The container provides reliable mechanical protection and preservation of amorphous material's properties. All materials comply with UL94V-1 / 0. 5x cores lot 120? Dimensions: 22.5mm-10.4-10.1 High tech modern production, perfect for Audio signal transformers as well as critical applications of Common Mode Chokes KEY FEATURES OF THE AMORPHOUS MATERIAL: Induction amplitude, Bm (25°C) 0.59 T Induction amplitude, Bm (90°C) 0.50 T Curie temperature, Tc 220°C Operating temperature range -60°C ... 100°C Magnetostriction less than 0.1?10^-6 Typical permeability (10 kHz) - 120 000 Typical permeability (100 kHz) - 35 000 ADVANTAGES: High permeability Decrease in choke size Decrease in the amount of winding turns Low active resistivity Low core loss Low wire loss High impedance in a wide frequency range Comply with IEC 950, EN 60950, BS 601 Low profile Full Manufacturers info: http://en.mstator.ru/products/cores/1a Free Trackable Airmail Shipping Worldwide!
