6/12/20/25mhz 3200p/3200p+ Double Ch Full Digital Control Dds Signal Generator

US $6700

Hong Kong, China
Nov 11th

Open on mobile:
QR code

6/12/20/25MHz 3200P/3200P+ Double CH Full Digital Control DDS Signal Generator The instrument Introduction MHS-3200P/P+ series instruments using large scale integrated circuits and high-speed FPGA MCU microprocessor, the internal circuit to take surface mount technology has greatly enhanced the instrument's noise immunity and service life. Display interface using LC1602 LCD display is divided into two lines, the top line shows the current frequency, the following line displays additional parameters or function variable and flexible use of flip key setting, greatly enhances the operability. This instrument signal generation, waveform scanning, as well as the use of parameter measurement has great advantages, is an electronic engineer, electronic laboratories, production lines and teaching, research and the ideal test, measurement equipment. Model Description This series of instruments in four models, the main difference is the maximum frequency sine wave, as follows: MHS-3200-06M sinusoidal signals at frequencies up to 6MHz MHS-3200-12M sinusoidal signals at frequencies up to 12MHz MHS-3200-20M sinusoidal signals at frequencies up to 20MHz MHS-3200-25M sinusoidal signals at frequencies up to 25MHz Parameters: - Signal: DC 0-80KHz - Output signal: 30mVp-p~30Vp-p - Maximum output current: 1A - Maximum output power: 2*15W - Output short circuit protection: YES - Output impedance: <= 1Ohm - Output phrase: same as the signal end - Distoration: <1% - Output signal Flatness: -+1db - Maximum frequency: 25Mhz Frequency : - Sine wave: MHS-3200P-06M: 0Hz-6Mhz - Square wave: 0Hz-6Mhz - Triangle wave: 0Hz-6Mhz - Serration wave: 0Hz-6Mhz - TTL signal wave: 0Hz-6Mhz - Output modulation: Frequency scanning - Sampling speed rato: 200MSa/s - Wave resolution: 8bits - Minimum frequency resolution: 10Mhz - Frequency tolerance: -+5 x 0.000001 - Frequency stability: -+1 x 0.000001 - Amplitude range: 15mVp-p~ 15Vp-p (<12MHz);15mVp-p~ 8Vp-p (>12MHz) - Output impedance: 50Ohm-+10% - TTL: - Low level: <0.3V - High level: 1V-7.5V - Scanning time: 1-500s - Counting range: 0-4294967295 - Storage number: 10 - Position: M0-M9 - Interface: USB to seriel port - Communication speed rato: 57600bps - Power : DC 12V - Size: 180x190x71 (mm) - Weight: 670g Package Included: - 1 x 12V 5A Power - 1 x USB - 2 x Clip line - 1 x power extended board - 1 x 4 channels TTL extended board Structure and function description 1. LCD1602 display 2. Status indicators 3. Operation button 4. Adjust knob 5. Ext.In the input interface 6. CH1 output interface 7. CH2 output interface 8. Power amplifier signal output port 9. DC12V power input interface 10.USB communication interface 11. TTL signal output port 12. Power switch Performance Testing 1.MHS-3200P + (broadband) power signal generator frequency range can be done 0-5MHz, the following shows the amplifier output frequency of 1MHz, amplitude of 30vp-p sine wave signal 2.MHS-3200P + (wide band) power signal generator frequency range can be 0-5MHz, the following shows the amplifier output frequency of 3MHz, the amplitude of 28vp-p sine wave signal 3.MHS-3200P + (wide-band) power signal generator frequency range can be 0-5MHz, the following shows the amplifier output frequency of 5MHz, amplitude of 30vp-p sine wave signal 4.MHS-3200P (ordinary type) amplifier output 5KHz sine wave drive two low-voltage incandescent (3200P ordinary type of current can be 1A, to drive the light bulb, and 3200P + broadband maximum current is 300mA, it can not drive this light bulb) 5.MHS-3200P (ordinary type) amplifier output two parallel maximum 2A current output can be achieved, it should be noted that the parallel is the premise that the two channels output the same frequency, the same amplitude, the phase difference of 0 ° 6. Amplifier output two-way series can achieve the maximum 60Vp-p voltage signal output, it should be noted that the premise of the two channels in the same frequency output, the same amplitude, the phase difference of 180 ° (3200P ordinary type and 3200P + Type can be achieved) We only accept payment through Paypal. Items will go to post within 1-2 business days after payment confirmed. Please leave note in PayPal when making the payment if you have any special request (colors / size). USA customers: All items will be shipped to address in buyer’s eBay details via ePacket service of USPS & China Post. We’ll offer tracking number for each package. Tracking info can be traced on USPS system (www.usps.com). Customers outside of USA: All items will be shipped to address in buyer’s paypal details via Hong Kong Post Air Mail. Before you bid item, please clear you have noticed below details: 7-20 working days: United States 10-30 working days: Canada, United Kingdom, Australia, Japan, New Zealand 2-5 working weeks: Countries in Western Europe, Southeast Asia, Israel, Korea 3-6 working weeks: Russia, Croatia, Eastern Europe, Mid-East 4-7 working weeks: Brazil, Mexico, South America We are unable to take any responsibility for any custom delay or tax. Reason is because transit time is highly depended and provided by Postal Service (except weekends and holidays). Normally, we leave positive feedback for you once payment received. We are also hope that you can do me the same. Your support will keep us moving forward forever. If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact me before you return it. If the shipping delay happened, we’re willing to pay refund or resend new item(s). eBay Cross Border Trade powered by Channel Effect On Nov-10-16 at 22:58:19 PST, seller added the following information:
