#6-3 Copper Vntc Thhn-pvc Tray Cable With Ground 200' Spooled + 15' ,102lbs

US $580

Westtown, New York, United States
Aug 9th

Open on mobile:
QR code

#6-3 copper THHN-PVC Tray cable with ground 200' + 15' 102lbs. #6-3 copper with ground THHN-PVC electric Tray cable wire 200' + 15' numbered. 6 AWG 3 Conductors + #8 Ground, ICEA Method 4 Color Code (Black & Numbered) PVC/Nylon/PVC, Control, Unshielded, 600V, UL Type TC-ER Color: Black Applications: In free air, raceways or direct burial. In wet or dry locations. Approved for direct burial, Class I, Div. 2 industrial hazardous locations per NEC. Permitted for Exposed Run (ER) use in accordance with NEC. Also Known As: raceway cable, underground cable, multi-conductor THHN cable, lighting cable, control cable, signal and communication circuit cable, etc. Features: Rated at 90°C dry, 75°C wet. Ripcord applied to all cables with jacket thickness of 60 mils or less. Provides outstanding sunlight, cold bend and cold impact resistance. Offers the smallest cable O.D. available for suitable applications. Provides long service life. Provides good oil and chemical resistance. Meets cold bend test at -25°C. Meets the crush and impact requirements of Type MC cable. Compliances: Industry Compliances: - UL 66 NEC Type TFN conductors - UL 1277 Type TC-ER for 3 or more conductors, UL File # E57179 - UL 1581 - ICEA S-95-658 Flame Test Compliances: - UL 1277 - IEEE 383 - IEEE 1202 - CSA FT4 Other Compliances: - EPA 40 CFR, Part 261 for leachable lead content per TCLP - OSHA Acceptable - RoHS Compliant Conductor Color Code: Black and numbered conductors Conductor: Fully annealed stranded bare copper to ASTM B3 Class B stranding per ASTM B8 Insulation: Flame-retardant Polyvinyl Chloride (PVC) with clear Polyamide (nylon) Color-coded per ICEA Method 4 Ground: Uninsulated bare annealed copper per ASTM B3 Class B stranding per ASTM B8 Jacket: Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC) Options: Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC) Specifications*: Size: 6 AWG Number of Conductors: 3 Conductor Strand: 7/.0612 Ground Wire Size: 8 AWG Minimum AVG Insulation Thickness: 0.91 mm / 0.036 inches Minimum AVG Jacket Thickness: 1.52 mm / 0.060 inches Outside Diameter: 17.53 mm / 0.690 inches Copper Weight: 0.300 lbs per ft Net Weight: 0.434 lbs per ft Allowable Ampacity: 75 Amps Bend Radius: 5 x overall diameter installed (up to 2.0") / 6 overall diameter installed (over 2.0") 8 x overall diameter during installation pull-in.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Sheath Color	Black
Current Rating	91-100 A
Insulation Material	Polyvinyl Chloride (PVC)
Conductor Material	Copper
Brand	Unbranded
Number of Conductors	4
Wire Style	Stranded
