6 Axis Mach3 Cnc Breakout Board Usb Interface Lpt & Hand Control &tool Sensor

US $430

Changzhou,Jiangsu, China
May 28th

Open on mobile:
QR code

Package: 1 x 6 Axis DDMMV2.1 March3 CNC breakout Board 1 x Hand controller 1 x Feeler block 1 x USB cable 1 x Parallel cable 1 x CD (CD include with English user manual and software and register code) 1. Products brief introduction DDMMV2.1, which name is short for “Digital Dream Multiple input Mach3 card Version 2.1”is a CNC system based mach3. This card is designed by our Studio You do not need to add other Hardware,and you can complete the signal conversion from the G-code to the movement of the stepper motor drive control. You should use both parallel port and usb port at the same time.This card is compatible with most stepper drives and servo drives. And it is perfect weapon to replace mach3 parallel interface board. 1) Computer system requirement Basic Configuration: 1) CPU: 1GHz; 2) Memory: 512MB 3) 500MB Available disk space 4) USB 2.0 5) LPT port Recommended configuration: 1) CPU: 2GHz Dual Core; 2) Memory: 2GB; 3) 1G Available disk space 4) USB 2.0 5) LPT port 2) Production appearance 1. USB communication interface, and power supply for the board; 2. LPT port for stepper driver signal. 3. 8 IO outputs ,opto-isolated; 4. Spindle outputs signal; 5. Hand control box port; 6. 6 axis stepper dirver signal output; 7. 15 IO input, opto-isolated, It Can be configured to limit the emergency stop and other functions. 8. Use STM32 chip as a Master ; 3) Detailed functional introduction A. Operating voltage of input interface: 12V; B. Operating voltage of output interface: 12V; C. Stepper motor control signal output voltage: 5V; NOTE: The marked as “Power In” is Power input interface, you should connected correctly. 2.Mach3 Manual Control Box V1.1 Mach3 Manual Control Box is a hand control box designed for mach3.It’s a box connected to Mach3 main Controller.Most instructions of Mach3 can be issued by this box.This box should be used with mach3 controller card DDMMV2.1. 1)Specfication 1. Comunicate with mach3 controller card by RS232 2. procedure control botton:START/HOLD/STOP/RESET 3. Jog botton:XYZABC 6 axis’ up and down 4. FRO,SRO,SJR setting botton 5. Other botton: like Home,Goto zero,Rewin Spindle run/stop 1.We accept Paypal for payment.all Paypal must be confirmed (shipping and billing address must match and correct) 2.Please pay within 3 days of order. 1. We'll ship it out within in 1 or 2 days after payment verified . 2. Please check out your address carefully when processing order.We are not responsible for wrong or undeliverable address. Delievry time USA,UK,Candana,Australia,New Zealand,Asia 7-15 business days EU(Germany,France,Spain,etc) 10-15 business days South America,other countries 15-25 business days 1.Defective or wrong item will be offered replacement or refunds after offer the pictures to prove it. 2.When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos.we will help you to solve all problems. 1.Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. 2.Please contact us before leaving any negative or neutral feedback.We will help you to solve any problems
