6 Ghz Pll Brick Oscillator, 10.2 Dbm Output

US $62

  • San Marino, California, United States
  • Jan 29th
Open on mobile:
QR code
6 GHz  PLL brick oscillator by California Microwave.   Contains a high-Q cavity oscillator (adjustable from 5.86 GHz to 6.35 GHz)  that is phase locked to a harmonic of the internal reference ovenized crystal oscillator.  Here, I am using a XTAL of 104.8 MHz, cavity oscillator runs at 1572 MHz, and the multiplier block is X4 giving output at 6288 MHz.  The output power is 10.2 dBm.  Requires a well-regulated  -20.0 VDC supply.   The spectrum analyzer (at 1 MHz/div), cables, attenuators, and the crystal are not included in auction.   This "brick" is in very nice clean condition, and it phase locks just fine.  Ships to USA for $7.00 via USPS Priority mail in antistatic bag and boxed.   No shipping out of USA.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand California Microwave
Model .
