60-160 Mhz VCO RF, voltage-controlled oscillator., US $300 – Picture 0
60-160 Mhz VCO RF, voltage-controlled oscillator., US $300 – Picture 0

60-160 Mhz Vco Rf, Voltage-controlled Oscillator.

US $300

  • default, Russian Federation
  • Jun 12th
Open on mobile:
QR code
Voltage-controlled oscillator VCO (60-160) MHz. Broadband Generator continuous harmonic signals in the frequency band: (60 ... 160) MHz. Control voltage: U = (0 ... 16) V. Output Power: (+6 ... + 13) dBm. The relative output of the second harmonic: -15 dBc. Output Impedance: Zout = 50 ohms. Supply voltage; E = (+ 7..+20) V, 110 mA Output RF connector: SMA Board size: 45 mm * 45 mm. Dependence of the voltage on the signal frequency (typ):   Uadj, (V). F1, (MHz) P1, (dBm) P2, (dBm) P3, (dBm) 0 59,6 +6,7 -8,2 -24,3 1 71,0 +8,3 -5,8 -23,4 2 78,9 +9,2 -4,3 -22,2 3 85,6 +9,7 -3,3 -19,7 4 92,1 +10,1 -2,5 -17,5 5 98,7 +10,4 -2,1 -15,6 6 105,8 +10,6 -1,5 -14,5 7 113,6 +10,7 -1,1 -14,5 8 122,1 +10,8 -0,45 -16,3 9 130,3 +10,8 -0,1 -19,3 10 138,2 +10,8 +0,33 -22,9 11 145,5 +10,8 +0,62 -23,1 12 151,9 +10,9 +0,61 -19,8 13 157,1 +10,9 +0,6 -17,3 14 160,9 +10,9 +0,6 -15,9 15 163,9 +10,9 +0,6 -15,1 16 166,2 +10,8 +0,5 -14,6
