60-160 Mhz VCORF,+20dBm High Power, sinusoidal,radio frequency broadband source, US $150 – Picture 0
60-160 Mhz VCORF,+20dBm High Power, sinusoidal,radio frequency broadband source, US $150 – Picture 0

60-160 Mhz Vcorf,+20dbm High Power, Sinusoidal,radio Frequency Broadband Source

US $150

  • default, Russian Federation
  • Oct 20th
Open on mobile:
QR code
Voltage-controlled oscillator VCO (60-160) MHz, the sinusoidal output High Power +20 dBm.  Radio frequency broadband voltage-controlled oscillator (rf oscillator VCO frequency source), continuous harmonic signals in the frequency band: (60 ... 160) MHz. Control voltage: U = (0 ... 15) V. Output Power: (+16 ... + 23) dBm. The relative output of the second harmonic: -15 dBc. Output Impedance: Zout = 50 ohms. Supply voltage; E = (+ 14..+20) V, 120 mA Output RF connector: SMA Board size: 45 mm * 45 mm. Dependence of the voltage on the signal frequency (typ):    Uadj, (V). F1, (MHz) P1, (dBm) P2, (dBm) P3, (dBm) 0 58,8 +16,3 -7,1 -22,1 1 70,7 +19,9 +0,3 -32,1 2 78,9 +20,8 +2,9 -19,5 3 85,9 +21,6 +5,4 -12,6 4 92,5 +22,3 +6,8 -8,3 5 99,3 +22,8 +8,8 -5,2 6 106,7 +23,1 +10,1 -1,1 7 114,4 +23,1 +11,1 +2,1 8 122,5 +22,6 +10,1 +3,8 9 130,8 +22,3 +10,6 +3,4 10 138,5 +21,8 +10,2 +2,3 11 145,7 +21,6 +9,9 +0,7 12 152,1 +21,5 +9,9 -1,3 13 157,6 +21,5 +10,6 -4,3 14 161,9 +21,5 +11,3 -7,9 15 165,4 +21,5 +11,3 -10,7 16 168,3 +21,4 +11,7 -13,1 17 170,7 +21,3 +11,2 -13,3 18 172,9 +21,3 +11,3 -12,7 I can reconfigure the VCO on your bandwidth. Write me a mail !!!
