640' Alumaflex Al Type Mc Wire Reel

US $820

New Brighton, Pennsylvania, United States
May 30th

Open on mobile:
QR code

AlumaFlex™ This Auction is for a 640' Reel of 900/4 AL MC CABLE - BLK, RED, BLU, WHT W/GROUND Specs and Product Notes from Southwire: 900 kcmil - with Triple E™ Aluminum Alloy Lightweight Aluminum Interlocked Armor with Overall PVC Jacket, 600 volts. AlumaFlex™ with Triple E™ Aluminum Alloy 8000 series (AA8176) Conductors. THHN/THWN-2 Insulated Singles. Bare Aluminum Grounding Conductor. Type MC Cable - "flame retardant sunlight resistant PVC Jacket" is suitable for use as follows: • Direct burial applications, installation in concrete and where exposed to cinder fills, strong chlorides, caustic alkalis, or vapors of chlorine or of hydrochloric acids. • Branch, feeder and service power distribution in commercial, industrial, institutional, and multi- residential buildings. • Power, lighting, control, and signal circuits. • Fished or embedded in plaster. • Concealed or exposed installations. • Places of Assembly per NEC 518.4 and theaters per NEC 520.5. • As aerial cable on a messenger. • Installation in cable tray and approved raceways. • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) & 645.5(D)(2). • Class I Div. 2, Class II Div 2, & Class III Div. 1 Hazardous Locations. Southwire AlumaFlex™ Type MC Cable with Triple E™ Aluminum Alloy - "PVC Jacketed" meet or exceed the following requirements: • UL 83 • UL 1569 • UL 1685 • Federal Specification A-A59544 (formerly J-C-30B) • Jacketed & Non Jacketed will both pass " UL Test" & "FT4/IEEE 1202"(70,000 Btu/hr) Vertical Cable Tray Flame Test • National Electrical Code • Listed for use in UL 1, 2, and 3 Hour Through-Penetration Firestop Systems • REACH/RoHS-2 (Chemical Limit) Compliant Southwire AlumaFlex™ Type MC Cable with Triple E™ Aluminum Alloy - "PVC Jacketed" is constructed with Aluminum Type THHN/THWN-2 conductors rated 90°C wet or dry, and a bare aluminum grounding conductor for sizes 1/0 AWG and larger. The conductors are cabled together and a binder tape is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly. • Lightweight aluminum armor--as much as 45% lighter than steel MC Cable. • Available with Southwire pulling heads and on stacked reels • Available in custom constructions and lengths • UL Classified 1, 2, and 3 hour Through Penetration Firestop Systems: W-J-3037, W-L-3110, W-L-3113, W-L-3117, W-L-3120, W-L-3121, W-L-3160, C-AJ-3115, C-AJ-3140, C-AJ-3142, C-AJ-3145, C-AJ-3173, C-AJ-3202, C-AJ-4065, C-AJ-4066, F-C-3038. • Cable reverse wound on reel for ease of pulling and installation. When pulling from coils, pull from inside to ensure ease of installation. • Anti-short bushings are not required for use with MC cable per the NEC and UL Phase Conductors No. of Conductor s Color Sequence 120/208Y Color Sequence 277/480Y 3 Black, Red, White Brown, Orange, Grey 4 Black, Red, Blue White Brown, Orange, Yellow, Grey Groundin g Conducto r Bare Bare Color sequence for other special colors are available subject to economic order quantity. · UL Online Certification Directory ( www.ul.com ) · UL Online Product Guide Info - Metal-Clad Cable (PJAZ) ( www.ul.com )
