640x480 Vga Sccb Ov7670 Image Sensor Mage Transducer Webcam Camera Module

US $13.50

Guangzhou ,Guangdong, China
Feb 27th

Open on mobile:
QR code

ov7670 Image sensor mage transducer Webcam camera Module SCM Acquisition module for photographing Description ov7670 Image sensor mage transducer Webcam camera Module SCM Acquisition module for photographing #1300216 OV7670 image sensor, providing single-chip VGA camera and image processor for all functions Through the SCCB bus control, outputFull frame, sub-sampling, taking a variety of windows, etc. affect the data resolution Products VGA images up to 30 frames / sec. Users can fully control the image quality, data formats and transmission. All image processing functions including gamma curve process, white balance, saturation, hue and so on through the SCCB interface programming. OmmiVision image sensor applications unique sensor technology, by reducing or eliminating optical or electronic defects such as fixed pattern noise, prop tail, floating powder, etc., to improve image quality, get a clear and stable color image. ● High sensitivity suitable for illumination applications ● Low voltage suitable for embedded applications ● Standard SCCB interface compatible with I2C interface ● RawRGB, RGB (GRB4: 2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output format ● Supports VGA, CIF, and from a variety of sizes CIF to 40x30 ● VarioPixel sub-sampling mode ● Auto affect the control features include: automatic exposure control, automatic gain control, automatic white balance, automatic elimination light stripes, automatic black level calibration image quality controls including color saturation, hue, gamma, sharpness ANTI_BLOOM ● ISP has a compensation function to eliminate noise and dead pixels ● Support for image scaling ● compensation for loss of optical lens ● 50/60Hz automatic detection ● Saturation automatically adjust (UV adjustment) ● Automatically adjust edge enhancement ● Noise Reduction automatically adjust Key parameters Photosensitive array: 640X480 IO Voltage: 2.5V to 3.0V (internal LDO for nuclear power 1.8V) Power operation: 60mW/15fpsVGAYUV Sleep: <20μA Temperature Operating: -30 ℃ to 70 ℃ Stable: 0 ℃ to 50 ℃ Output Formats (8)? YUV/YCbCr4: 2:2 RGB565/555/444 GRB4: 2:2 Raw RGB Data Optical size: 1/6 " FOV: 25 ° Maximum Zhen rate: 30fps VGA Sensitivity: 1.3V / (Lux-sec) SNR: 46 dB Dynamic range: 52 dB View Mode: Progressive Electronic Exposure: 1 line to 510 line Pixel Size: 3.6μm x 3.6μm Dark current: 12 mV / s at 60 ℃ packing incluidng: 1x ov7670 Image sensor mage transducer Payment We only accept payments via paypal. All payments must be prepaid, no Cash and COD payment. We will ship the item to the address on your paypal payment notice, Please confirm your shipping address in the PayPal Account. If you have any problem about payment , please contact us. Delivery details Item will be shipped within 3 working days after full payment is received. We ship worldwide with flat rate shipping by post Air mail, the shipment usually takes 15-45 business days . We can also provide express post by EMS(5-8 days) or UPS(4-5 days). The cost is higher than standard postage, extra shipping fees is needed. if you need express post please contact us ! About us We will leave positive feedback to buyer as soon as buyer pays for the item .Your satisfaction is our first priority. Please leave us positive feedback upon satisfaction of the item. Please email us before leaving negative and neutral feedback. We will try our best to solve the issue. We will leave positive feedback to buyer as soon as buyer pays for the item . Contact us we do try respond as quickly as possible. Due to time zone difference, please allow 12~24 hours to get your mail replied. If you have any questions, Please contact with us via ebay message or our customer service e-mail .thanks for your buying ,wishes you have a happy shopping from our shop ! Engineered for professional eBay sellers!
