65 Ton 9" Thrt Scotchman 6509-24m made In The Usa New Ironworker, Single Opera

US $17,790.00

Harrison, New Jersey, United States
Mar 12th

Open on mobile:
QR code

Thousands of Used Metalworking and Plastic Machines & New Machine Tools Photos, Full Descriptions and Prices - Fast & Easy About Us Shipping Payments & Checkout FAQs Our Inventory Home CNC Machines Manual Lathes, Mills, Drills, Saws Grinders, Hones, Finishing Fabricating Equipment Presses & Feeds Boring Mills Automatic Screw Machines EDMs Inspection Equipment Air Compressors Plastic Machinery Planers & Planer Mills Broaches & Keyseaters Shapers & Slotters Tooling & Accessories Welding Equipment Wire & Fastener Ovens, Furnaces & Environmental Misc Metalworking Gear Machinery Material Handling Misc Non-Metalworking 65 Ton 9" Thrt Scotchman 6509-24M *Made in the USA* NEW IRONWORKER, single opera 65 Ton 9" Throat Scotchman 6509-24M *Made in the USA* NEW IRONWORKER, single operator; 3 stations; 5 Ref #: 136587 iammdna XNEWIR NEW SCOTCHMAN 65 TON IRONWORKER MODEL: 6509-24M *MADE IN THE USA* STANDARD FEATURES: 65-ton punch station (1-1/16" in 3/4") Keyed punch ram for safety 9" throat depth Punch gauging table with fence and scale Die holder complete with 2" die insert Punch nut with wrench and stripper One round punch & die: max. diameter 1-1/4" Punch jog control Adjustable electric stroke control with scale Electric remote foot pedal 24" flat bar shear with 4-way reversible blade Shear table with miter fence Angle shear capacity @ 90 degrees: 6" x 6" x 3/8" and 5" x 5" x 1/2" Tool table work area Two-stage hydraulic pump Electrical box supplied with emergency palm button and lock-out tag-out accommodations 230/460 volt/3-ph electrics (must specify voltage) All guards necessary to comply with ANSI B 11-5 standards Forklift accommodations Three-year warranty on parts CAPACITIES AND SPECIFICATIONS: RATED ON A36 MILD STEEL/65,000 PSI TENSILE Punching capacity .................................. 65 ton (58 mt) .................................. 1-1/16" in 3/4" (27 mm in 18 mm) Special tooling .................................... 4" max. dia. (100 mm max. dia.) Throat depth ....................................... 9" (225 mm) Flat bar shear ..................................... 24" length (600 mm) ..................................... 1" x 6" (25 x 150 mm) ..................................... 3/4" x 10" (18 x 250 mm) ..................................... 1/2" x 12" (12 x 300 mm) ..................................... 3/8" x 16" (10 x 400 mm) ..................................... 1/4" x 24" (6 x 600 mm) Opt. Sabre blade ................................... 1" x 6" (25 x 150 mm) ................................... 1/2" x 16" (12 x 400 mm) Angle shear 90 degrees ........................................ 6" x 6" x 3/8" (150 x 150 x 10 mm) ........................................ 5" x 5" x 1/2" (125 x 125 x 12 mm) 45 degrees ........................................ 3" x 3" x 3/8" (75 x 75 x 10 mm) (w/Bar shear) ..................................... 4" x 4" x 1/2" (100 x 100 x 12 mm) Brake 12" .......................................... 40 ton (36 mt) Brake 24" .......................................... 30 ton (27 mt) Open end brake ..................................... Max. 1/4" x 5" (6 x 125 mm) flat or angle iron Pipe notcher ....................................... 3/4", 1" (19 mm, 25 mm) Schedule 40 ....................................... 1-1/4" (32 mm) ....................................... 1-1/2", 2" (38 mm, 50 mm) Rectangle notcher .................................. 2" x 2-1/2" x 3/8" (50 x 65 x 10 mm) 90 degree V-notcher ................................ 6" x 6" x 5/16" (150 x 150 x 8 mm) Channel shear ...................................... 2" to 5" adj. (50 mm to 125 mm adj.) Strut shear ........................................ samples required Rod shear Round rod (max.) .................................. 1/4" to 1-1/4", 9 cavity (6 mm to 32 mm) Square rod (max.) ................................. 1/4" to 1", 1 cavity (6 mm to 25 mm) Square tube shear .................................. 1/2" to 2", 12 gauge (12 to 50 mm, 2.75 mm) Picket tool ........................................ 1/2", 3/4", 1" (12 mm, 19 mm, 25 mm) ........................................ 16 gauge (1.6 mm) Offset die holder .................................. Max. 40 ton (36 mt) Strokes per minute In light material ................................. 67 spm (1/4" stroke) [punch station] In heavy material ................................. 22 spm (3/4" stroke) [punch station] Hydraulics ......................................... 2,600 psi (183 bar) Motor Standard .......................................... 5 hp 3 ph (3.73 kW) 230/460/208/380/575v Optional .......................................... 5 hp 1 ph (3.73 kW) 230v Dimensions ......................................... 60" L x 24" W x 66" H ......................................... (152 cm x 57 cm x 168 cm) Shipping weight .................................... 2,984 lbs. (1,353 kg) OPTIONAL STANDARD TOOLING (CALL FOR PRICING): 12" & 24" brake Open end brake Pipe notcher 90 degree V-notcher Rectangle notcher 6" x 6" die holder Channel shear Tube shear Rod shear Picket tool Offset die holder Unequal leg angle blades Punch slug receptacle Strut shear Urethane stripper Brake length gauge with scale (12" & 24" brakes) Brake table with scale & squaring arm (12" & 24" brake) Multi-loc punch gauging table (36" and 85" extensions available) 48" back gauge Hydraulic hold-down Laser light Tool table extension with punch and die storage 24" x 5' conveyor with angle iron support Punch table extension *We will meet or beat virtually any price on the web. We also offer special financing deals with integrated discounts for qualified customers. Machine Location: HARRISON, NJ Click Here For More Scotchman Machines Click Here For More Fabricating Machine - NEW IRONWORKERS(s) Questions about this Machine? Call Kori at (800) 873-6224 ext 7567 Need a Freight rate? Call Alex, our recommended trucking and shipping broker at (973) 732-3274 effepbdc Finance This Equipment For Your Business - Click Here Buy With Confidence Machinery Values is one of the world's largest machinery dealers, in business since 1971. All used items bought from our eBay store are covered by a standard MDNA (Machinery Dealer's National Association) 30 day return privilege, which means you can return an item you are dissatisfied with for a full refund. Please click on our MDNA return privilege link for complete details on how this works. New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines. Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this. We are a Certified Square Trade Seller - click on the Square Trade logo for details. Questions? Call us at: (973) 497-7500 Shipping Policy Will ship to Worldwide. TOP Payments & Checkout We accept PayPal, Visa & MasterCard and American Express, or contact us regarding other payment options. Please contact us soon after the auction ends (or Buy-It-Now ends listing) to tell us how you wish to pay and get any shipping quotes or pickup information you may require. Call Terry at 973-497-7612 regarding payments, and Alex at 973-497-7613 for shipping questions. TOP Frequently Asked Questions We offer a 30 day return privilege on all used machines sold from our stock (machines sold for clients and shipped from their plant locations are generally not covered - so ask if you’re in doubt). This return privilege is the industry standard MDNA return privilege which states the machine must be returned freight prepaid in the same condition it was shipped in (you can’t break it then return it) for a full refund of your purchase price, excluding shipping costs. TOP

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Scotchman
Model	6509-24M Made in the USA

65 Ton 9" Thrt Scotchman 6509-24m *made In The Usa* New Ironworker, Single Opera
