7.5kw 34a 220v 10hp Vfd Inverter Single Phase Speed Variable Frequency Drive

US $39.99

US, United States
Jul 24th

Open on mobile:
QR code

DESCRIPTION This VFD can be used for constant torque loads ( such as hard starting: Air compressors, HVAC units) and variable torque loads (such as pumps, fans, etc). It can be used as a motor speed control and a phase converter. The input for this VFD is 1 phase . You can control the different speed as you like when yo use this VFD. Many customer bought this VFD from us to use for: Lathes, Mills, Car Hoists, Pumps & Conveyors, etc and then performance excellently. This item use Sine wave PWN(SPWM ) for the control system and performance excellently. How To Install This VFD Symbol:Function Description R.S.T:Input terminal of AC line power.220V class for single phase, single phase connected to any two phases U.V.W:Output terminal of the inverter P+.PR:Connector for braking resistor. E:Ground terminal: the third method of grounding for 220V. Frequency Control Range:0.1~2500.0Hz Accuracy:Digital: 0.1%-10~40℃; Analog: 0.1% 25±10℃ Setting Resolution:Digital: 0.1Hz; Analog: 1‰ of max. Operating frequency Output Resolution:0.1Hz Operator Setting Method:Press directly ←∧∨ to set. Analog Setting Method:External Voltage 0-5V0-10V4-20mA0-20mA. Other Functions:Frequency lower limit, starting frequency, stopping frequency, three skip frequencies can be respectively set. General Control Ramp Control:Selectable 4-speed steps ramp-up and -down time (0.1-6500s). Torque Control:Torque increase settable by max. 10.0%. The starting torque can reach 150% at 1.0Hz. Multi-Inputs:6 multi-function input terminals for 8–speed steps control, program operation, switching of 4-speed Ramp, UP/DOWN function, counter, external emergency stop and other functions. Multi-Outputs:5 multi-output for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings. Other Functions:Auto Voltage RegulationAVR, Decelerating Stop or Coasting Stop, DC Braking, Auto Reset and Restart, Frequency Track, PLC Program Control, Traverse Control, Drawing ControlAuto Energy Saving, Carrier Adjustable (Up to 20KHz), etc. Protection Functions Overload Protection:Electronic relay protection motor drive.Drivefor constant torque 150%/1 min. for the kinds of fan 120%/1min. Fuse Protection:When the fuse breaks , the motor will stop. Over-voltage 220V classDC Voltage 400V. Under-voltage 220V classDC Voltage 200V. Restart After Instant Stop:Restart with Frequency Track after Instant Stop Stall Protection:Stall protection in ramp operation Output Short Circuit:Electrical circuit protection Other Functions:Fin over-heat protection, restriction of reverse running, direct start after power on, fault reset, parameter lock PID, one-drive-more, etc. SPECIFICATIONS Input Voltage220V Output Voltage208-240VAC ( analogous to Input Voltage ) Input Frequency48-63 Hz Output Frequency0-400 Hz Input Phase1 or 3 phase as you like Output Phase3 phase Control ModeSPWM Input Power220V class220±15% Working Temperature-10~40 ℃ Humidity0-95% Relative Humidity (without dew) VibrationBelow 0.5G DimensionDimension: 38 x 29 x 29 cm (L x W x H) IN THE BOX 7.5KW Variable Frequency Drive Inverterx 1 English manualx 1 FEATURE Our item adopts the Japan Mitsubishi chip PID control; advanced calculus PID closed-loop arithmetic Easy PLC function can realize 16 legs of speed and inverter control function With extremely strong anti-jaming capability Low output ratting torque 0.5HZ-150%, low speed running ability Carrier adjustable by 16KHZ, completely soundless working environment Broad voltage working area Auto voltage regulation (AVR) technique, for ensuring the inverter load capability Various control technique by both synchronization and non-synchronization With perfect error protection and short circuit starting protection capability; ISO9001 quality certifications which means this item is the top quality item; 5-Digits Display & Status Indicator Lamp : Displaying frequency, current, revolution, voltage, counter, temperature, FOR or REV rotation, and fault, etc.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	FANS-AUTO
Series	HY inverters
MPN	VFDST-S5
Power	7.5KW
Model	GDF-D75W
Inpute Phase	1 or 3 phase
Output Phase	3 Phase
Input Voltage	220 V
Control Mode	SPWM
Output Voltage	208-240VAC ( analogous to Input Voltage )
Outpute Frequency	0-400 Hz
Input Power	220V class220±15%
Inpute Frequency	48-63 Hz
Working Temperature	-10~40
UPC	Does not apply
