8- Lumex Lds-c512ri Leds 9 Hdlg-2416 Leds 5 Variable Resister Pots More On Board

US $11.95

Bel Air, Maryland, United States
Jun 9th

Open on mobile:
QR code

8- Lumex LDS-C512RI LEDS 9 HDLG-2416 LEDS 5 variable Resister pots more on board This board has 17 LED units, a bunch of pots and other push button switches. Displays are soldered to board. I leave the removal to the buyer. Sold as is. Overview Specifications Documentation This is a 5.0 mm (0.2 inch) four character 5 x 7 dot matrix display driven by an on-board CMOS IC. This display is pin for pin compatible with the HPDL-2416. The IC stores and decodes 7 bit ASCII data and displays it using a 5 x 7 font. Multiplexing circuitry, and drivers are also part of the IC. The IC has fast setup and hold times which makes it easy to interface to a microprocessor. The address and data inputs can be directly connected to the microprocessor address and data buses. The HDLG-2416 has several enhancements over the HPDL -2416. These features include an expanded character set, internal 8 level dimming control, external dimming capability, and individual digit blanking. Finally, the extended functions can be disabled which allows the HDLG-2416 to operate exactly like an HPDL-2416 by disabling all of the enhancements except the expanded character set. HDLx-2416, Four Character 5.0 mm (0.2 inch) 5x7 Alphanumeric Displays Features Enhanced Drop-in Replacement to HPDL-2416 Smart Alphanumeric Display Built-in RAM, ASCII Decoder, and LED Drive Circuitry CMOS IC for Low Power Consumption Software Controlled Dimming Levels and Blank 128 ASCII Character Set End-Stackable Categorized for Luminous Intensity; Yellow and Green Categorized for Color Low Power and Sunlight Viewable AlGaAs Versions Wide Operating Temperature Range 40 degrees C to 85 degrees C Excellent ESD Protection Wave Solderable Wide Viewing Angle (50 degrees typ) Manufacturer: Lumex Product Category: LED Displays & Accessories RoHS: Details Brand: Lumex Display Type: 7 Segment Number of Digits: 1 Character Size: 0.56 in Illumination Color: Green Wavelength: 565 nm Configuration: Common Cathode If - Forward Current: 10 mA Vf - Forward Voltage: 2.2 V Maximum Operating Temperature: + 85 C Minimum Operating Temperature: - 40 C Mounting Style: Through Hole Luminous Intensity: 3500 ucd Power Consumption: 105 mW Product: LED Display Most of the items I sell are USED. Lots of them are over 20 years old. This means that the items may have small nics and marks on them. You should not expect and for the most part, the item will not be in perfect cosmetic condition. I will make every effort to describe the items as completely as possible. I take lots of pictures so check the pictures carefully. I clean each and every item I sell but you may find a spot I have missed. If the item is new it will be stated in the ad. My shipping takes into account the time and materials that it takes to get ready for shipment. If you have an issue please contact me right away. I will make it right. I want every customer to be 100% satisfied! Thank you for your understanding!

Condition	For parts or not working : An item that does not function as intended and is not fully operational. This includes items that are defective in ways that render them difficult to use, items that require service or repair, or items missing essential components. See the seller’s listing for full details.
Seller Notes	“Used.”
