8-Port 100BaseFX Fiber Unmanaged Switches SIGNAMAX 065-7310FST, US $899.99 – Picture 0
8-Port 100BaseFX Fiber Unmanaged Switches SIGNAMAX 065-7310FST, US $899.99 – Picture 0

8-port 100basefx Fiber Unmanaged Switches Signamax 065-7310fst

US $899.99

  • Tuscaloosa, Alabama, United States
  • Feb 16th
Open on mobile:
QR code
Signamax Connectivity Systems' 8-Port 100BaseFX Fiber Switch is a plug-and-play Fast Ethernet switch that is the ultimate in easy 100Base FX fiber connection for simple multimode fiber applications. Standard 1U high non-blocking switch chassis supports eight multimode SC or eight multimode SC ports; each is equipped with a DIP switch for full or half-duplex mode selection. KEY FEATURES Plug ‘n Play - No Software Needed Switchable Duplex Modes True Non-Blocking Architecture Full Wire Speed Forwarding SC and ST Multimode Versions Five Year Performance Warranty SPECIFICATIONS APPLICABLE STANDARDS IEEE 802.3u 100BaseFX IEEE 802.3x Flow Control PORTS Model 065-7310FSC: 8 - Fixed 100BaseFX ports, SC multimode Model 065-7310FST: 8 - Fixed 100BaseFX ports, ST multimode FIBER INTERFACE, ALL MODELS: Type: LED Wavelength: 1300 nm nominal (1270 nm maximum, 1380 nm minimum) Maximum Output Power: - 14.0 dBm Minimum Output Power: - 20.0 dBm Sensitivity: -33.0 dBm Maximum Input Power: - 8.0 dBm Link Power Budget: 13.0 dB Maximum distance: 2,000 meters with 62.5/125 or 50/125 micron multimode fiber cabling LED STATUS INDICATORS Per Switch: Power Per Port: Link/Activity, 100 Mbps detected, Full Duplex/ Collision PERFORMANCE Throughput: 148,810 packets per second (pps) (64-byte packets) Switch Fabric Speed: 1.6 Gbps. Address Table Size: 2,048 entries PHYSICAL CHARACTERISTICS Dimensions: 17.3"W x 8.1"D x 1.75"H (440 mm x 205 mm x 45 mm) Weight: 6.2 lbs. (2.8 kg.) Mounting: Desktop or wall mounting ENVIRONMENT Operating: Temperature: 32°F to 122°F (0°C to 50°C) Relative Humidity: 10 to 90%, non-condensing Altitude: 3,048 meters (10,000 feet) Non-Operating/Storage: Temperature: -13°F to 158°F (-25°C to 70°C) Relative Humidity: 10 to 90%, non-condensing ELECTRICAL CHARACTERISTICS Maximum Wattage: 15 Watts Current: 4.0 Amps maximum Voltage: 100 to 240 Volts AC Frequency: 50 to 60 Hz. Heat Dissipation: 85 BTU per hour EMISSIONS FCC part 15 Class A, CE Mark Class A, VCCI Class
“BOX HAS BEEN OPEN ALL PARTS ARE NEW”
Model 065-7310FST
Accessories Included Rack Ears, Software
Number of Ports 8
UPC 763474115655
