8" Stroke Linear Actuator With Mounting Bracket Dc12v 225lbs Load For Recliner

US $32.59

  • Multiple Cities, United States
  • Jul 16th
Product Description Specification: Stroke length = 200mm(8"); Retracted length = 305mm(12"); Extended Length= 505mm(19.9“); Travel speed = 0.39 inches/sec (10 mm/s);Maximum current draw = 3Amps; Maximum Load = 225lbs(900N). Material: High quality aluminum alloy material, sturdy enough and with fashion look, High performance motor ,Built-in high quality limit switch Low noise: The low noise design, noise level below 50 dB IP54 rated: (suitable for outdoor use). Commonly Used In Automotive, Medical Devices and Engineering Industry, massage sofa, recliner, TV lifter, lifting table, electric window opener etc. Package Included: 1pc 12V 8" Linear Actuator with 2pcs mounting brackets. Specification:  Color: Black  Material: Aluminum Alloy  Input Voltage: DC 12V  Rated Current: 3Amp  Stroke length = 200mm(8")  Retracted length = 305mm(12");  Extended Length= 505mm(19.9")  Rated Load: 900N  Travel Speed: 10mm/s  Limit Switch: Built-in  Working Temperature: -20C to 65C  Protection Class: IP54  Duty Circle: 25%  Noise Level: <50dB  How To Install  1. Prepare to connect the two wires of the actuator to a 12 volt battery  2.Blue wire to the positive terminal and grey wire to negative terminal will make the actuator extend. To make it retract, just reverse the terminal connections.  3.To simplify the last step, you can prepare a reverse polarity relay or switch (not included) for the actuator. When you want the actuator to extend and retract, just press the switch  4. Your actuator will hold its position when the power is off. It will automatically stop when reaches the end.  5.The actuator has pre-installed inner limit switch, it cannot be adjustable.  6. I comes with mounting brackets.  How to protect your actuator:  1. Please use the 12V DC power adapter  2. Please do not exceed the rated load  3. All the actuators have duty cycle, they are unable to work all the time without stop. The duty cycle of this actuator is 20%. it means that your actuator needs 4 minutes to rest for every 1 minute of work. If the actuator keeps working for long time, the motor is easily burnt out.  4. Please be careful, the actuator not completely waterproof  Widly Use:  Furniture and home application  Hospitals and healthcare  Industrial and construction application  Agricultural machinery  Package Included:  1 X 8" Linear Actuator  2 X Mounting Bracket  1 X Screw Set About Us Payment Shipping Returns Contact Us Our goal is to make your choice easier and save your money. We serve customers world-wide by offering quality goods at unbeatable prices, all while maintaining a focus on superior customer service.Please feel free to ask any questions you may have via ebay messabe system, all questions will be answered promtly (usually in less then 24 hous except weekends and holidays).  We accept PayPal payments only. To avoid initiating an unpaid item case, please pay within 4 days. We will start processing your order once your payment has been cleared and verified. 1.We do everything we can to ship your orders out as soon as possible. 2.Shipping and Handling: -->NOTE:Additional shipping fee will be charged for buyers from Puerto Rico, Hawaii, Alaska, Guam, the U.S. military address of the United States and The nonnative American address Please contact our customer service for the details of extra shipping fee,thanks. -->For domestic economic shipping,It normally takes 2-8 days for delivery.we mayship your order(s) from different warehouses for expedited delivery as we utilize alternative warehouse across the Continental United States. You may upgrade to UPS 3-day Selected which delivery time is typically 1-3 business day. -->For International Orders,items may be shipped from our warehouse in south China. Both are the same products and same warranty. Duties and taxes may apply. Pleasa check with your country’s Custom and eBay policy for more information. Out 30-day Satisfaction Guarantee assures our customers that they will receive all orders promptly and exactly as described. In addition , it allows customers to return new and unused products in their original factory condition for any reason within 30 days from the date of purchase. Notice: 1.All returns must be pre-approved by Autopartm and have a return merchandise authorization (RMA) number. Unauthorized returns will not be accepted. 2.Buyers are responsible for appropriate packing, returning shipping cost, insurance and returning the item in “new” condition. Used items will not be accepted for return. 3.We will replace the returning item with an identical item, issue a full refund. Our Working Time:(GMT+8)Monday to Friday,9:00-18:00. For inquiries and customer support, please send your email via ebay email system. All emails will be responded to within 24 hours during business days. About Us Our goal is to make your choice easier and save your money. We serve customers world-wide by offering quality goods at unbeatable prices, all while maintaining a focus on superior customer service.Please feel free to ask any questions you may have via ebay messabe system, all questions will be answered promtly (usually in less then 24 hous except weekends and holidays).  Payment We accept PayPal payments only. To avoid initiating an unpaid item case, please pay within 4 days. We will start processing your order once your payment has been cleared and verified. Shipping 1.We do everything we can to ship your orders out as soon as possible. 2.Shipping and Handling: -->NOTE:Additional shipping fee will be charged for buyers from Puerto Rico, Hawaii, Alaska, Guam, the U.S. military address of the United States and The nonnative American address Please contact our customer service for the details of extra shipping fee,thanks. -->For domestic economic shipping,It normally takes 2-8 days for delivery.we mayship your order(s) from different warehouses for expedited delivery as we utilize alternative warehouse across the Continental United States. You may upgrade to UPS 3-day Selected which delivery time is typically 1-3 business day. -->For International Orders,items may be shipped from our warehouse in south China. Both are the same products and same warranty. Duties and taxes may apply. Pleasa check with your country’s Custom and eBay policy for more information. Returns Out 30-day Satisfaction Guarantee assures our customers that they will receive all orders promptly and exactly as described. In addition , it allows customers to return new and unused products in their original factory condition for any reason within 30 days from the date of purchase. Notice: 1.All returns must be pre-approved by Autopartm and have a return merchandise authorization (RMA) number. Unauthorized returns will not be accepted. 2.Buyers are responsible for appropriate packing, returning shipping cost, insurance and returning the item in “new” condition. Used items will not be accepted for return. 3.We will replace the returning item with an identical item, issue a full refund. Contact Us Our Working Time:(GMT+8)Monday to Friday,9:00-18:00. For inquiries and customer support, please send your email via ebay email system. All emails will be responded to within 24 hours during business days. powered by You may also like 4 Pack 5.28 Gallon Hydroponic Deep Water Culture DWC Hydroponic Bucket Grow kits 145.99 USD Free shipping 14"Black Stroke Linear Actuator with Mounting Bracket for TV Table 12V DC,225LBS 50.95 USD Free shipping 5.5"-20"Heavy-Duty Aluminum Lazy Susan Ring,Rotating Ring Turntable Swivel Plate 12.53 USD Free shipping 4Pack Folding Fish Rod Holder Stainless Steel Fish Rod Ground Support Pole Stand 18.99 USD Free shipping DC12V 22Inch Modern Linear Actuator With Mounting Bracket 900N(225lbs), 10mm/s 53.58 USD Free shipping 2 Pack 3-Tubes Rod Holder Stainless Steel Wall Side Mounted Fishing Rod Holders 36.99 USD Free shipping 5Pack Wall Mount Stair Handrail Brackets Stainless Steel w/Base For Round Tubing 15.85 USD Free shipping 2PCS 3/4'' Fuel Swivel 360 Degree,Swivel Connector for Fuel Nozzle Transfer Hose 29.95 USD Free shipping 1 Pack Modern Taiyaki Fish Shaped Cake Pan Waffle Cake Maker Double Tray Design 17.99 USD Free shipping 3/4" Fuel Swivel,Fuel Transfer Hose Swivel,360 Degree Rotation Nozzle Connector 16.99 USD Free shipping 2PCS 2"Dia.Sliding Gate Roller Steel V-Type Wheel Stainless Steel For Gate Frame 18.79 USD Free shipping 4Pack Air Conditioner Mounting Bracke Rubber Vibration Isolator, Mini Split Air 13.55 USD Free shipping
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand DasMarine
Protection Class IP54
Color Black
Rated Current 3Amp
Country/Region of Manufacture China
Rated Load 900N
Duty Circle 25%
Stroke Length 200mm(8")
Material Aluminum Alloy
Travel Speed 10mm/s
MPN DA-L210716C-001
Voltage DC 12V
UPC Does not apply
