8 Unit My4in 12vdc Omron New...

US $370

maia, default, Portugal
Jan 29th

Open on mobile:
QR code

novo 8 unit MY4IN 12VDC Classification of Products Monostable Relays standard type Ratings Coil 12 VDC 75 mA Coil Resistance 165 Ohm Operating voltage (voltage Set) 80% Max Release voltage (voltage reset) 10% Min Power consumption (stable Single) 0.9 W Indicator LED operation indicator Cop Killer increase not equipped Contact Type 4PDT Method of Single Contact Contact material Contact material Body: Ag Contact finish: Au coated Contact rated load 250 VAC 3 A (resistive load (cos phi = 1)) 250 VAC 0.8 A (Inductive load (cos phi = 0.4)) 30 VDC 3 A (resistive load) 30 VDC 1.5 A (Inductive load (L / R = 7 ms)) Maximum switching voltage 250 VAC (Phi resistive load (cos = 1)) 250 VAC (inductive load (cos phi = 0.4)) 125 VDC (resistive load) 125 VDC (Inductive load (L / R = 7 ms)) Maximum switching current AC: 5 A (Resistive load (cos phi = 1)) AC: 5 A (Inductive load (cos phi = 0.4)) DC: 5 A (resistive load) DC: 5 A (Inductive load (L / R = 7 ms)) Maximum power switching AC: 660 VA (resistive load (cos phi = 1)) AC: 176 VA (inductive load (cos phi = 0.4)) DC: 72 W (resistive load) DC: 36 W (Inductive load (L / R = 7 ms)) Failure rate of 1 mA at 1 VDC (failure level: P reference value) Operating temperature: -55 to 60 CEL (with no icing or condensation) Operating environment humidity: 5 to 85% RH (with no icing or condensation) character Max contact resistance 50 mOhm, Measuring the voltage drop across the contacts by applying test / current as 5 VDC voltage 1 A Operating time (set) 20 ms max. Release time (Reset time) 20 ms max. Frequency Max.operating (Mechanical) 18000 OPN. / H Frequency Max.operating (Erectrical) 1800 OPN. / H Insulation Resistance Between coil and contacts: 100 MOhm Min (500 VDC) between contacts of different polarity: 100 MOhm Min (500 VDC) between contacts of same polarity: 100 MOhm Min (500 VDC) Dielectric strength between coil and contacts: 1,500 VAC 50/60 Hz for 1 min (Leakage current 3 mA 50/60 Hz 1 min) Among contacts of different polarity: 1500 VAC 50/60 Hz for 1 min (Leakage current 3 mA 50/60 Hz 1 min) Among contacts of same polarity: 1000 VAC 50/60 Hz for 1 min (Leakage current 3 mA 50/60 Hz 1 min) Vibration resistance (destruction) 10 to 55 10 Hz only 0.5 mm width (1.0 mm double amplitude) for 2 hours each in the X, Y, and Z (n defect in appearance and construction after applying vibration to each variable of instructions for 2 hours). Vibration resistance (Breakdown) 10 to 55 10 Hz 0.5 mm single amplitude (1.0 mm double amplitude) in each direction Shock resistance (destruction) 1000 m ** 2 each direction 3 times / s (No defect in appearance and construction after applying shock in each directions 3 times.) Shock resistance (error) 200 m / s ** 2 (Contacts must not open for a month or more after the relay is subjected to a shock in each direction three times.) Endurance (Mechanical) 100000000 operations min. Endurance (Electrical) 200,000 operations min. Protective Structure enclosed type (cover) Applicable standard (UL) Standard No.: UL508 file in:. E41515 Applicable standard (CSA) Standard No.: C22.2 No.0, No.14 file in:. LR31928 Applicable standard (Other) Conformed standard 2: Electrical Appliance and Material Safety Law Terminal Structure Plug-in Approx. 35 g

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	IFM
Model	IE5072
