8ch Thermocouple Pt100 Cu50 V/a Thermometer Data Logger Recorder 7'' Tft Lcd

US $800.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you order. Standard Accessories: NAPUI-1 temperature module with 8CH thermocouples, power cord(AU, US, UK and Euro plug), software, PDF manual, Optional accessories: Li-batteries, other temperature modules with thermocouples. Model 130T PC interface Equipped with Ethernet (100 Base-TX) interface OS Must be installed in advance the following any version of the operating system: Windows vista Ultimate, Windows Vista Business, Windows Vista Home Premium, Windows Vista Home Basic, Windows XP Professional, Windows XP Home Edition, Windows2000 Professional. Language support English/simplified Chinese/traditional Chinese processor Pentium III equivalent to more than 1 GHz clock frequency above (1.7 GHz clock frequency Suggestions above) Memory capacity More than 256MB (suggestions for 512MB above), using the Windows Vista is more than 512MB (suggestions for 1GB above) Installation required memory capacity 100MB display screen High Color(16bit) above, Resolution 1024 * 768 pixels above, display Color High Color (16 bit) above, 7 inches printer 300 dpi above When using Excel transmission function Install the Excel above 97 version When using HTTP server (Web server) function Install the Internet Explorer5.5 (Service Pack2) above version When using FTP server Install a FTP terminal function application software Model NAPUI130T high precision input measuring unit Input methods Floating don't balance between input CH, CH-other units, power port FG insulation resistance measurement between port, the insulation between for CH Number of frequency band input 8CH (support max. 64CH, need pay extra for them) Measurement period The fastest sampling inspection period 1 s (1 ch, AD total time 1 s) to 9999 s Synchronize the measuring unit ±100ps bellow AD transform way ??way AD Resolution 16bits AD cumulative time 2ms, 16.7ms, 20ms Input types Voltage, ±10V, ±5V, ±1V, ±0.5V, ±0.1V, 1-5V thermocouple K, J, E, R, S, B and N, temperature measuring the resistance body Pt100, Cu503 zone current 1 mA logic voltage regulation, logical contact Benchmark contact compensation Can internal/external switch (points respectively, external set band set to 0C) Benchmark contact compensation accuracy ±0.5C(23C±5C, the input port when temperature balance) Maximum input voltage (rated) ±60V Input resistance Thermocouple, voltage 1 v the following, logic contacts 100 M ? above Voltage 1-5 V. 5 V level or above, logic voltage About 1 M ? Withstand voltage Measured input port-FG port, and between box 1500VAC (50/60 Hz) Measured input port, and a power between port Measured input ports between each other (other between units) Measured input ports between each other (the same units) 600VAC (50/60Hz) Input signal source resistance Voltage: thermocouple 2 K ? below temperature resistance body 1 line 10 ? the following (3 line are equal) temperature resistance body Thermocouple level (detection current: about 64 pA), 1-5 V range (detection voltage: less than 0.58 V) Burn out test cycle According to measurement cycle for testing Measurement range Input type Can measure range Measurement accuracy (AD total time 16.7 ms, 20 ms) Display resolution ±10V -11.000V to +11.000V ±0.5%of rdg±2 digit 1mV ±5V -5.500V to +5.500V ±0.5%of rdg±2 digit 1mV ±1V -1.1000V to +1.1000V ±0.5%of rdg±2 digit 0.1mV ±500mV -550.0m to +550.0mV ±0.5%of rdg±2 digit 0.1mV ±100mV -110.00mV to +110.00mV ±0.5%of rdg±2 digit 0.01mV 1-5V +0.800V to +5.200V ±0.5%of rdg±2 digit 1mV 4-20mA +0.38mA to +21.00mA ±0.5%of rdg±2 digit 0.01mA K -100°C to +1372°C ±0.5%of rdg±0.6°C 0.05°C -200°C to -100°C ±0.5%of rdg±0.9°C J -100°C to +1200°C ±0.5%of rdg±0.6°C 0.05°C -200°C to -100°C ±0.5%of rdg±0.8°C E -100°C to +1000°C ±0.5%of rdg±0.6°C 0.05°C -200°C to -100°C ±0.5%of rdg±0.8°C T -100°C to +400°C ±0.5%of rdg±0.5°C 0.01°C -200°C to -100°C ±0.5%of rdg±0.8°C N 0°C to +1300°C ±0.5%of rdg±0.6°C 0.05°C W +1500°C to +2315°C ±0.5%of rdg±1.1°C 0.05°C 0°C to +1500°C ±0.5%of rdg±0.8°C R +300°C to +1768°C ±0.5%of rdg±0.8°C 0.05°C 0°C to +300°C ±0.5%of rdg±1.6°C S +300°C to +1768°C ±0.5%of rdg±0.9°C 0.05°C 0°C to +300°C ±0.5%of rdg±1.6°C B +400°C to +600°C ±0.5%of rdg±1.7°C 0.05°C +600°C to +1820°C ±0.5%of rdg±1.0°C Pt100 -200°C to +660°C ±0.5%of rdg±0.3°C 0.02°C CU50 -50°C to +150°C ±0.5%of rdg±0.3°C 0.02°C Preheating time More than 30 minutes Ability to adapt to the environment Surrounding temperature 0C to +50C surrounding humidity 20% to 85%RH(No condensation) Weight About 2.8Kg Data save Built-in 64M flash memory; Support U disk(U disk is not included in the package) As long as the U disk insert TP series recorder, can set the start time and end time to save data to a U disk. Thus, without the need to replace the chart recorder paper operation and traditional data recorder trouble button operation. Flexible operation The instrument can be flexible to your company to provide the change of the design service, measuring unit not only can be removed and installation of input and output module, and its structure can tear open next port sets, can reduce Settings, wiring, time, support hot swaps (both in power-on state directly plug measuring unit module), operate up is very convenient.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	NAPUI130T
Country/Region of Manufacture	China
MPN	NAPUI130T
