8mhz Dual Channel Dds Function Signal Generator Sine/square Wave Sweep Fre

US $89.88

Shen Zhen, China
Apr 26th

Open on mobile:
QR code

8MHz Dual Channel DDS Function Signal Generator Sine/Square Wave Sweep fre 8MHz Dual Channel DDS Function Signal Generator Sine/Square Wave Sweep +Counter Model: FDY2208S Manual download: http://www.filedropper.com/fy22xxsv20 Introduction of the instrument FY22xx(S)Introduction of the instrument This manual applies to FY22xxS series function of DDS signal generator of various models. FY22xxS instrument model two digits after the XX said the model instrument frequency limit (MHz). This instrument adopts large scale CMOS integrated circuit, high speed microprocessor, the internal circuit USES active crystals do benchmark, high signal stability. Using surface patch process, greatly improving the anti-interference performance and service life of the instrument. Instrument has dual DDS signal output, can generate sine wave, square wave, triangle wave, sawtooth wave, the output signal's amplitude, offset, phase of implementation process control. Both TTL output, frequency measurement and counter, and other functions, FY22xxS series with linear sweep and logarithmic frequency sweep function, can set arbitrary scanning frequency range and scanning time. Is the electronic engineers, laboratory, production line and the ideal equipment of teaching, scientific research, at the same time can also be used as industrial equipment form a complete set of modules. It has excellent technical indexes and function features: ?High frequency precision, frequency precision can reach 10-6 orders of magnitude ?High frequency resolution: full range of 10 MHZ frequency resolution ?Main wave of adjustable duty ratio (1% ~ 99%) ?No range limit: full range of frequency step, direct digital Settings ?High precision waveform: value calculated by the function, of output waveform synthesis, waveform of high precision, small distortion ?A variety of waveform: sine, square wave, triangle wave, sawtooth wave ?Scanning features: frequency linear and logarithmic function, scan scanning load-point any Settings ?Storage features: can store 20 groups of users to set the state of instrument parameters, can be called up again ?Operation mode: all keystrokes, LCD1602 LCD English display, direct digital continuous adjusting Settings or knob?High reliability, large scale integrated circuit and SMT technology, high reliability, long service life ?Frequency measurement: with 60 MHZ frequency meter functions, the internal/external signal frequency measurement ?Main technology indexes Primary and secondary wave output channel two-way high-speed independent outputs. Output sine wave, square wave (variable duty cycle), triangle wave, sawtooth wave. Output amplitude ≥ 20Vp-p (no load) Output Impedance 50Ω ± 10% ± 5V DC bias Sine wave frequency range 0.01Hz ~ 2MHz (FY2202S) 0.01Hz ~ 5MHz (FY2205S) 0.01Hz ~ 8MHz (FY2208S) 0.01Hz ~ 10MHz (FY2210S) 0.01Hz ~ 12MHz (FY2212S) Square-wave frequency range 0.01Hz ~ 2MHz (FY2202S) 0.01Hz ~ 4MHz (FY2205S, FY2208S, FY2210S, FY2212S) Frequency resolution 0.01Hz (10mHz) Frequency Accuracy ± 5 × 10-6 Frequency stability ± 2 × 10-6/3 hours Sine wave distortion ≤ 0.8% (reference frequency is 1kHz) Triangle wave linearity ≥ 98% (0.01Hz ~ 10kHz) Rise and fall time of square wave ≤ 100ns Square wave duty cycle range from 1% to 99% ? TTL output Dual TTL-level output, adjustable phase Frequency Range 0.01Hz ~ 2MHz/5MHz/8MHz/10MHz/12MHz Amplitude> 3Vp-p Fanout factor> 20 TTL loads ? COUNTER counter function Counting range 0-4294967295 Measurement frequency range 1Hz ~ 60MHz Input amplitude 1Vp-p ~ 20Vp-p u scan function (this function only with the main wave) Scanning linear sweep, logarithmic sweep Frequency Range 0.01Hz ~ 2MHz/5MHz/8MHz/10MHz/12MHz Frequency sweep range frequency ~ M2 M1 default preset frequency Scan rate 1s ~ 99s / stepper u Other Display LCD1602 LCD display in English Storage and transferred functions M0-M19 (M0: Default transferred) Size 200mm (length) × 190mm (width) × 90mm (height) Weight 500 grams (bare metal), accessories (150 g) Buzzer function can be set to turn on or off through the program Surface mount technology manufacturing process, LSI High reliability, long life Operating characteristics of all key operations, continuous adjustment knob Environmental conditions Temperature: 0 ~ 40 °C Humidity: <80% Wide supply voltage range AC85 ~ AC260V We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products.
